30 Chapter 3
Removing the Side Panel
1. Perform the pre-disassembly procedure described on page 28.
2. Remove the two screws (A) located on the rear edge of the side panel.
3. Slide the side panel toward the back of the chassis until the tabs on the cover disengage with the slots on
the chassis.
4. Lift the side panel away from the system and put it aside for reinstallation later.
Screw (Quantity) Color Torque Part No.
#6-32 L5 BZN (2) Black 5.7 to 6.3 kgf-cm 86.00J07.B60
