19
Chapter 2 Setting Up the Gateway
8. The next window appears. Plug the phone filter into the Phone Jack on the
back of the Gateway. Do not plug the phone filter into the phone jack on the
back of the computer. The connections should look exactly as the configura-
tion in the picture, below (if the first computer is connected via USB; if the
first computer is connected via Ethernet, the yellow cable will be plugged into
one of the yellow ports). Click Next
Next, go to “Setting Up the DSL Connection,” below.
Setting Up the DSL Connection
After connecting the Gateway and installing filters, the DSL connection must be
configured. To do this:
1. When the following window appears, read the onscreen instructions, then
click Next.
