Actiontec Wireless-Ready DSL Gateway User Manual
LAN IP Address
Selecting LAN IP
Address in the “Advanced Configuration” screen generates the
LAN IP Address” screen. The value in the
LAN IP
Address text box is the IP
address of the Gateway as seen on the network.
The
LAN IP address of the Gateway can be modified, but Actiontec recommends
keeping the default factory setting (192.168.0.1).
Note:Ifthe Gateway’s LAN IP Address is modified, verify the
DHCP Server range is within the same subnet. For more infor-
mation, see “DHCP Server Configuration.”
DHCP Server
Selecting DHCP Server in the “Advanced Configuration” screen generates the
DHCP Server” screen. The Gateway has a built-in DHCP (Dynamic Host
Configuration Protocol) server that automatically assigns a different IP address to
each computer on the network, eliminating IP address conflicts.
The factory default setting is On.To disable the DHCP Server, select Off.
