Actiontec electronic GS204AD9-01 Network Card User Manual



46
Actiontec Wireless-Ready DSL Gateway User Manual
DNS
Server 2 - the secondary DNS provided by the Internet Service
Provider (ISP).Ifthe ISP provided secondary DNS server infor-
mation, enter it here. If not, leave the text box intact.
Services Blocking
Selecting Services Blocking in the “Advanced Configuration” screen generates the
“Services Blocking” screen.
To modify Internet privileges (Web,
FTP,Newsgroups, etc.) for the computers on
the network:
1. Enter the computer’s IP address in the Enter
IP Address: text box.
2. Select the Internet service(s) to be blocked.
3. Click Add to enter the computer’s IP address in the “Blocked IP Address List”
text box.
4. To remove blocked services, select the computer’s IP address in the “Blocked
IP Address List” text box and click Remove.
Netmeeting
To allow the computers on the Gateway’s network to access Netmeeting, enter the
Netmeeting IP address in the IP text box, then select On.IfNetmeeting is not
needed, select Off.
