ADDONICS TECHNOLOGIES
AD4IN1EXC34 (4 In 1 Express Card 34 Digiadapter)
SPECIFICATIONS
• Express card 34 slot
• Complete Plug and Play
• Rugged and reliable stainless steel cover
• Ideal for small form factor and sealed systems
• Reads and writes to four different popular digital media -
Memory Stick Duo ™, Memory Stick™, Multimedia
Card™, Secure Digital Card™
• Power from express card slot - no adapter necessary
System Requirements
• Windows 98SE, Me, 2000, XP
• Mac OS 8.6, 9.x, 10.1.2 or higher
• Available Express Card Slot
INSTALLATIONS
The following diagram shows how to install the card into your
system.
1. First insert the card into an available Express Card slot on
your system.
2. When inserted, insert flash media into existing express
card slot.
Software Driver Install:
This card should be plug and play compatible on all supported
systems, and does not require any other drivers.
Usage:
The Addonics 4-in-1 DigiAdapter ExpressCard 34 is a great option
for Notebook users which have the new ExpressCard 34 slot to read
small size ultra flash cards, including Memory Stick™, Memory
Stick Duo ™, Secure Digital Card™ or Multimedia Card™. This
ExpressCard DigiAdapter is lightweight, durable, and almost half
the size of a PCMCIA card form factor, fitting easily into a pocket
or even a wallet. The ExpressCard DigiAdapter flushes completely
into the ExpressCard slot, making it the ideal solution for
convenient transportation even when inserted into Notebook.
Trouble Shooting:
Q. Where do I access the flash media?
A. Under Windows you should be able to see the new drive in
my computer under removable storage. On Macintosh you should
see a new drive come up named UNTITLED DISK.
Q. Why can’t I see the flash media on my system?
A. Verify the flash media is inserted properly into the Express Card
adapter and make sure the media is either; Memory Stick,
Memory Stick Duo, Multi Media Card, or Secure Digital.
Make sure the adapter is pushed in the slot completely and is flush
with your system.
Q. Why can’t I get the card out?
A. Since the adapter rests flush with the system you will need to
press button on the side of your express card slot.
Q. Why doesn’t this card fit in my system?
A. Make sure the label on the card is face up, also make sure the
slot is an express card slot and not a PCMCIA. This card will only
fit in an express card slot. If you need a PCMCIA type digiadapter,
you may check out our site at, http://www.addonics.com for a
PCMCIA/Cardbus solution. If it is an express card 54 slot, make
sure you put the card in the top section of the slot.
Technical Support
Addonics Technologies Phone: 408 433-3899
2466 Kruse Drive Fax: 408 433-3898
San Jose CA 95131
Email: sales-team@addonics.com
Internet: http://www.addonics.com
Technical Support (8:30 am to 5:30 pm PST)
Phone: 408 433-3855
Email: techinfo@addonics.com
