ADDONICS TECHNOLOGIES
ADN1GEX34 (Gigabit Ethernet ExpressCard Adapter)
SPECIFICATIONS
• Fully compliant with IEEE 802.3 (10Base-T
Ethernet), IEEE 802.3u (100Base-TX Fast
Ethernet), IEEE 802.3z (1000Base-T Gigabit
Ethernet)
• Compliant with PCI Express Specification, revision
1.0a
• 1-lane 2.5Gbps ExpressCard/34 host interface
• RJ-45 Port offer high speed transmission over CAT
5 UTP cable
• LEDs indicators for various network activities
• Auto-Negotiation with Next page capability
• Supports pair swap/polarity/skew correction
• Crossover Detection & Auto-Correction
• Microsoft® NDIS5 Checksum Offload (IP, TCP,
UDP) and largesend offload support
• Supports Full Duplex flow control (IEEE 802.3x)
• Supports IEEE 802.1Q VLAN tagging
• 8K Transmit FIFO and 64K Receive FIFO support
• Hot-plug capability
• Drivers for Windows 2000, Windows XP and
Windows Server 2003
• Dimension (W x D x H) - 106 x 34 x 15 mm
• Weight - 34 grams
INSTALLATION
Hardware Installations:
1. Insert the Gigabit Ethernet ExpressCard Adapter to
the system’s ExpressCard slot.
Windows 2000, XP & 2003 Driver Installations
1. The Found New Hardware Wizard pops on the
screen. Place the Addonics driver disk into the
CDROM drive.
2. Found New Hardware Wizard: Can Windows
connect to Windows Update to search for
software? Select “No, not at this time” Click
Next.
3. The Generic Marvell Yukon Chipset base
Ethernet Controller is identified.
4. Found New Hardware Wizard: What do you
want the wizard to do? Click Next to select the
default.
5. When the new hardware wizard has finish
installing the Ethernet ExpressCard driver,
click Finish to complete the installations.
Confirming Gigabit Ethernet Driver Installation
1. Right click the My Computer icon and select
properties.
2. Click Device Manager in the Menu Tree.
3. Click the “+” sign in front of Network
Adapters. Generic Marvell Yukon Chipset
based Ethernet Controller should appear.
TECHNICAL SUPPORT
Addonics Technologies Phone: 408 433-3899
2466 Kruse Drive Fax: 408 433-3898
San Jose CA 95131
Email: sales-team@addonics.com
Internet: http://www.addonics.com
Technical Support (8:30 am to 5:30 pm PST)
Phone: 408 433-3855
Email: techinfo@addonics.com
