Version 1.0, 2003/11/06
Panel Panel Type TFT LCD
Panel Size 17.0" (431.8mm)
Max. Resolution SXGA 1280 x 1024
Pixel Pitch 0.264mm
Brightness 250cd/m
2
(Typical)
Contrast Ratio 500:1 (Typical)
Surface Treatments Hard coating, anti-glare
treatment, anti-static
Viewing Angle (H/V) 170°/170° (Typical)
Display Color 16.7M
Response Time (R/F) 15ms / 10ms (Typical)
Frequency (H/V) H: 24kHz - 80kHz
V: 50Hz - 75Hz
Max. Pixel Clock 135MHz
Life Time 50,000hrs (Minimum)
Input Analog 15-Pin D-Sub
Audio Audio In 3.5mm audio line-in
Audio Out 3.5mm headphone jack
Speaker 2W x 2
Connector Power 3-Pin AC Plug
Thickness 3.0mm (0.18")
Reflection Rate <1%
Transmission Rate >96%
NeoV Optical
Filter
Hardness >6H (MOH’s Rating)
Tilt Tilt 5° ~ 25°
Mounting VESA FPMPMI Yes (100mm)
Dimensions Net (W x H x D) 400 x 390 x 171 mm
(15.8" x 15.4" x 6.7")
Packing (W x H x D) 555 x 171 x 580 mm
(21.9" x 6.7" x 22.8")
Weight Net Weight 6.2Kg (13.6lbs)
Gross Weight 8.0Kg (17.7lbs)
Regulation
Approval
Safety & EMI UL/CUL, TUV/BAURT, CE,
NEMKO, DEMKO, FIMKO,
SEMKO, CB, TCO 95, FCC,
BSMI, VCCI, CCC, GOST
VESA DDC 1/2B, DPMS
Power Power AC 100 - 240V, 50 - 60Hz
Consumption <48W (On)
<3W (Stand-by)
<3W (Off)
* All specifications are subject to change without prior notice.
Global Headquarters
Associated Industries China, Inc.
T: 886-2-2357-5896
F: 886-2-3393-2475
www.neovo.com
Europe
AG Neovo Technology B.V.
T: 31-10-442-57-37
F: 31-10-442-57-42
www.agneovo.nl
North & South America
AG Neovo Technology Corp.
T: 1-408-321-8210
F: 1-408-321-8211
www.neovo-usa.com
Asia Pacific & Middle East
Associated Industries China, Inc.
T: 886-2-2357-5896
F: 886-2-3393-2475
www.neovo.com
E-17B
f 17” LCD DISPLAY
Exceptionally elegant exterior
Stylish rear side design
Crisp 500 contrast ratio
170° wide viewing angle
NeoV Optical Filter
Built-in speakers with headphone jack
Auto-adjustment for optimal setting
Intuitive OSD with key lock function
Kensington
security slot
VESA standard wall mount
f FEATURES
f SPECIFICATION
f CONTACT INFORMATION
