P/C: E19H0 Version 11.0, 20070720
Panel Panel Type TFT LCD
Panel Size 19.0" (483mm)
Max. Resolution SXGA 1280 x 1024
Pixel Pitch 0.294mm
Brightness 300cd/m
2
(Typical)
Contrast Ratio 700:1 (Typical)
Surface Treatments Hard Coating (2H), Anti-glare
Treatment
Viewing Angle (H/V) 150°/135° (Typical)
Display Color 16.7M
Response Time 4ms (GTG)
Frequency (H/V) H: 24kHz - 80kHz
V: 56Hz - 75Hz
Max. Pixel Clock 135MHz
Life Time 50,000hrs (Typical)
Input Analog 15-Pin D-Sub
Digital 24-Pin DVI-D
Audio Audio In 3.5mm Audio Line-in
Audio Out 3.5mm Headphone Jack
Speaker 1W x 2
Connector Power 3-Pin AC Plug
Thickness 3.0mm (0.18")
Reflection Rate <1%
Transmission Rate >96%
NeoV Optical
Glass
Hardness >6H (MOH’s Rating)
Tilt Tilt +5° ~ +25°
Mounting VESA FPMPMI Yes (100mm)
Regulation
Approval
Certifications &
Compliance
UL/CUL, TUV/BAURT,
NORDIC, CB, FCC, CE, BSMI,
EPA, GOST, WEEE, RoHS
VESA DDC 2B, DPMS
Power Power AC 100 - 240V, 50 - 60Hz
Consumption <55W (On)
<2W (Stand-by)
<1W (Off)
Dimensions Net (W x H x D) 437 x 450 x 196mm
(17.2" x 17.7" x 7.7")
Packing (W x H x D) 555 x 580 x 171mm
(21.9" x 22.8" x 6.7")
Weight Net Weight 7.3Kg (16.1lbs)
Gross Weight 9.5Kg (21.0lbs)
Packing 1 Pallet 30 Cartons
20’ Container 360 Sets
40’ Container 720 Sets
All specifications are subject to change without prior notice
f 19
”
LCD DISPLAY f SPECIFICATION
E-19
f FEATURES
Exceptionally elegant exterior
Stylish rear side design
Swift 4ms response time
Crisp 700 contrast ratio
NeoV Optical Glass
TM
Dual digital and analog inputs
Built-in speakers with headphone jack
Auto-adjustment for optimal setting
Intuitive OSD with key lock function
Kensington
security socket
VESA standard wall mount
www.agneovo.com
Copyright © 2007 AG Neovo. All rights reserved.
The name AG Neovo is a trademark of Associated Industries China, Inc.
All other trademarks are the property of their respective owners.
