P/C: HW2200 Version 4.1, 20080312
Panel Panel Type TFT LCD
Panel Size 22.0" (559mm)
Max. Resolution WSXGA
+
1680 x 1050
Pixel Pitch 0.282mm
Brightness 300cd/m
2
(Typical)
Contrast Ratio 1000:1 (Typical)
Surface Treatments Hard Coating (3H), Anti-glare
Treatment
Viewing Angle (H/V) 170°/160° (Typical)
Display Color 16.7M
Response Time 3ms (GTG)
Frequency (H/V) H: 24kHz – 83kHz
V: 55Hz – 75Hz
Max. Pixel Clock 150MHz
Life Time 50,000hrs (Minimum)
Input Analog 15-Pin D-Sub
Digital 24-Pin DVI-D
Audio Audio In 3.5mm Audio Line-in
Speaker 2W x 2
Connector Power 3-Pin AC Plug
Tilt Tilt -5° ~ +25°
Mounting VESA FPMPMI Yes (100mm)
Regulation
Approval
Certifications &
Compliance
UL/CUL, FCC, NOM, CB, CE,
TUV/GS, GOST-R/HYGIENIC,
Nordic, BSMI, Energy Star,
TCO’03, WEEE, RoHS
VESA DDC-2B, DDC-CI
Power Power AC 100 - 240V, 50 - 60Hz
Consumption <48W (On)
<2W (Stand-by)
<1W (Off)
Dimensions Net (W x H x D) 506 x 405 x 211 mm
(19.9” x 15.9” x 8.3”)
Packing (W x H x D) 591 x 522 x 174 mm
(23.3” x 20.6” x 6.9”)
Weight Net Weight 4.9 kg (10.8 lbs)
Gross Weight 5.9 kg (13.0 lbs)
Packing 1 Pallet 48 Sets
20’ Container 480 Sets
40’ Container 960 Sets
All specifications are subject to change without prior notice.
f SPECIFICATION
f 22
”
WIDESCREEN LCD DISPLAY
H-W22
f FEATURES
22” widescreen format
WSXGA
+
1680 x 1050 resolution
Slim and sleek design
Fast 3ms response time
Crisp 1000 contrast ratio
Built-in HDCP for HD-format video
Integrated speakers
Auto-adjustment for optimal viewing
Easy-to-use friendly OSD
Kensington
security socket
VESA standard wall mount
Windows Vista Premium approved
TCO’03 certified
