P/C: RXW900_RXW901 Version 1.1 20071031
Panel Panel Type TFT LCD
Panel Size 19" (481mm)
Max. Resolution WXGA
+
1440 x 900
Pixel Pitch 0.285mm
Brightness 380cd/m
2
(Typical)
Contrast Ratio 1000:1 (Typical)
Viewing Angle (H/V) 170°/160° (Typical)
Display Color 16.7M
Response Time 5ms (GTG)
Frequency (H/V) H: 24kHz – 80kHz
V: 56Hz – 75Hz
Max. Pixel Clock 150MHZ
Life Time 50,000hrs (Minimum)
Input Connector Analog 15-Pin D-Sub
Digital 24-Pin DVI-D
BNC Security BNC Connector
Input Signal Analog RGB H.V Sync
Digital TMDS
Auto Composite System NTSC/PAL/SECAM
Output
Connector
BNC Security BNC Connector
Thickness 3.0mm (0.18") NeoV Optical
Glass
Reflection Rate <1%
Transmission Rate >96%
Hardness >6H (MOH’s Rating)
Tilt Tilt 0° ~ +20°
Mounting VESA FPMPMI Yes (100mm)
Certifications &
Compliance
FCC, UL/CUL, NOM, CB, CE,
TUV/Baurt, BSMI, NORDIC,
GOST, WEEE, RoHS
Regulation
Approval
VESA DDC 1/2B, DDC-CI
Power Power Source 100 - 240V, 50 - 60Hz
Consumption <48W (On)
<1W (Off)
Temperature Operation 0°C ~ 40°C
Storage -20°C ~ 60°C
Dimensions Net (W x H x D) 448 x 351 x 155 mm
(17.6” x 13.8” x 6.1”)
Packing (W x H x D) 534 x 472 x 195 mm
(21.0” x 18.6” x 7.7”)
Weight Net Weight 5.4kg (11.8 lbs)
Gross Weight 7.9kg (17.5 lbs)
1 Pallet 48 Sets
20’ Container 480 Sets
Packing
40’ Container 960 Sets
All specifications are subject to change without prior notice
f 19” WIDE SECURITY LCD DISPLAY f SPECIFICATION
R
X
-W19
www.agneovo.com
Copyright © 2007 AG Neovo. All rights reserved.
The name AG Neovo is a trademark of Associated Industries China, Inc.
All other trademarks are the property of their respective owners.
f FEATURES
High 1440 x 900 WXGA
+
resolution and high
contrast ratio 1000:1
Image sticking (burn-in) prevention function
added to secure your investment
Quick signal-switching time (≤ 0.8 sec.)
Real-time displaying the image upon signal
connection
V
ideo input settings will resume when power
re-plug
Looping video inputs for multiple connections
Auto termination
Supports NTSC/PAL/SECAM video system
Supports color and B/W picture
Selectable signal source
PC & Mac compatible
Auto-adjustment for optimal settings when
VGA input is selected
NeoV Optical Glass
TM
Slim border & bezel design
Distinctive metal alloy housing for added
strength
Kensington
security socket
VESA standard wall mount
