Panel Panel Type TFT LCD
Panel Size 22.0" (559mm)
Max. Resolution WSXGA
+
1680 x 1050
Pixel Pitch 0.282mm
Brightness 300cd/m
2
(Typical)
Contrast Ratio 900:1 (Typical)
Viewing Angle (H/V) 170°/160° (Typical)
Display Color 16.7M
Response Time 5ms (GTG)
Frequency (H/V) H: 24kHz – 83kHz
V: 50Hz - 76Hz
Max. Pixel Clock 160MHZ
Life Time 30,000hrs (Minimum)
Input Connector Analog 15-Pin D-Sub
Digital 24-Pin DVI-D
BNC Security BNC Connector
Input Signal Analog RGB H.V Sync
Digital TMDS
Auto Composite System NTSC/PAL/SECAM
Output
Connector
BNC Security BNC Connector
Thickness 3.0mm (0.18") NeoV Optical
Glass
Reflection Rate <1%
Transmission Rate >96%
Hardness >6H (MOH’s Rating)
Tilt Tilt 0° ~ +20°
Mounting VESA FPMPMI Yes (100mm)
Certifications &
Compliance
FCC-B, UL/CUL, NOM, CB,
CE, TUV/Baurt, BSMI,
NORDIC, GOST, WEEE,
RoHS,
Regulation
Approval
VESA DDC 1/2B, DDC-CI
Power Power Source 100 - 240V, 50 - 60Hz
Consumption <48W (On)
<1W (Off)
Temperature Operation 0°C ~ 40°C
Storage -20°C ~ 60°C
Dimensions Net (W x H x D) 512 x 392 x 155 mm
(20.2” x 15.4” x 6.1”)
Packing (W x H x D) 586 x 508 x 195 mm
(23.1” x 20.0” x 7.7”)
Weight Net Weight 6.9kg (15.2 lbs)
Gross Weight 10.5kg (23.1 lbs)
1 Pallet 40 Sets
20’ Container 400 Sets
Packing
40’ Container 840 Sets
All specifications are subject to change without prior notice
f 22” WIDE SECURITY LCD DISPLAY f SPECIFICATION
R
X
-W22
www.agneovo.com
Copyright © 2007 AG Neovo. All rights reserved.
The name AG Neovo is a trademark of Associated Industries China, Inc.
All other trademarks are the property of their respective owners.
f FEATURES
High 1680 x 1050 WSXGA
+
resolution and
high contrast ratio 900:1
Image sticking (burn-in) prevention function
added to secure your investment
Quick signal-switching time ( 0.8 sec.)
Real-time displaying the image upon signal
connection
V
ideo input settings will resume when power
re-plug in
Looping video inputs for multiple connections
Auto termination
Supports NTSC/PAL/SECAM video system
Supports color and B/W picture
Selectable signal source
PC & Mac compatible
Auto-adjustment for optimal settings when
VGA input is selected
NeoV Optical Glass
TM
Slim border& bezel design
Distinctive metal alloy housing for added
strength
Kensington
security socket
VESA standard wall mount
