P/C: SX15B0_SX5B1 Version 9.0, 20070731
Panel Panel Type TFT LCD
Panel Size 15" (381mm)
Max. Resolution XGA 1024 x 768
Pixel Pitch 0.297mm
Brightness 400cd/m
2
(Typical)
Contrast Ratio 500:1 (Typical)
Viewing Angle (H/V) 140°/125° (Typical)
Display Color 16.7M
Response Time 8ms (GTG)
Frequency (H/V) H: 30kHz - 60kHz
V: 56Hz - 75Hz
Max. Pixel Clock 80MHz
Life Time 30,000hrs (Minimum)
Input Connector Analog 15-Pin D-Sub
Digital 24-Pin DVI-D
BNC Security BNC Connector
Input Signal Analog RGB H.V Sync
Digital TMDS
Auto Composite System NTSC/PAL/SECAM
Output
Connector
BNC Security BNC Connector
Thickness 3.0mm (0.18") NeoV Optical
Glass
Reflection Rate <1%
Transmission Rate >96%
Hardness >6H (MOH’s Rating)
Tilt Tilt 0° ~ +20°
Mounting VESA FPMPMI Yes (100mm)
Certifications &
Compliance
FCC, UL/CUL, TUV/BAURT,
CE, BSMI, ISO 13406-2,
GOST, WEEE, RoHS
Regulation
Approval
VESA DDC2B, DPMS
Power Power Source 100 - 240V, 50 - 60Hz
Consumption <25W (On)
<1W (Off)
Temperature Operation 0°C ~ 40°C
Dimensions Net (W x H x D) 380 x 155 x 359mm
(15.0" x 6.1" x 14.1")
Packing (W x H x D) 438 x 210 x 470mm
(17.2" x 8.3” x 18.5")
Weight Net Weight 4.8Kg (10.6 lbs)
Gross Weight 7.0Kg (15.4lbs)
1 Pallet 40 Cartons
20’ Container 480 Sets
Packing
40’ Container 1040 Sets
All specifications are subject to change without prior notice
f 15” SECURITY LCD DISPLAY f SPECIFICATION
S
X
-15
f FEATURES
Looping video inputs for multiple
connections
Auto termination
Quick signal-switching time (≤0.8 sec.)
Supports color and B/W picture
Automatic NTSC/PAL/SECAM scan system
selectable
Selectable signal source
PC compatible
Auto-adjustment for optimal setting
NeoV Optical Glass
TM
Distinctive metal alloy housing for added
strength
Kensington
security socket
V
ESA standard wall mount
www.agneovo.com
Copyright © 2007 AG Neovo. All rights reserved.
The name AG Neovo is a trademark of Associated Industries China, Inc.
All other trademarks are the property of their respective owners.
