AG Neovo SX-17 Computer Monitor User Manual



P/C: SX17E0_SX7E1 Version 13.0, 20070731
Panel Panel Type TFT LCD
Panel Size 17" (432mm)
Max. Resolution SXGA 1280 x 1024
Pixel Pitch 0.264mm
Brightness 300cd/m
2
(Typical)
Contrast Ratio 800:1 (Typical)
Viewing Angle (H/V) 160°/160° (Typical)
Display Color 16.7M
Response Time 3ms (GTG)
Frequency (H/V) H: 30kHz - 80kHz
V: 56Hz - 75Hz
Max. Pixel Clock 135MHz
Life Time 50,000hrs (Minimum)
Input Connector Analog 15-Pin D-Sub
Digital 24-Pin DVI-D
BNC Security BNC Connector
Input Signal Analog RGB H.V Sync
Digital TMDS
Auto Composite System NTSC/PAL/SECAM
Output
Connector
BNC Security BNC Connector
Thickness 3.0mm (0.18") NeoV Optical
Glass
Reflection Rate <1%
Transmission Rate >96%
Hardness >6H (MOH’s Rating)
Tilt Tilt 0° ~ +15°
Mounting VESA FPMPMI Yes (100mm)
Certifications &
Compliance
FCC, UL/CUL, TUV/BAURT,
CE, BSMI, ISO13406-2, CB,
GOST, WEEE, RoHS
Regulation
Approval
VESA DDC2B, DPMS
Power Power Source 100 - 240V, 50 - 60Hz
Consumption <48W (On)
<1W (Off)
Temperature Operation 0°C ~ 40°C
Dimensions Net (W x H x D) 408 x 398 x 175mm
(16.1" x 15.7" x 6.9")
Packing (W x H x D) 495 x 510 x 228mm
(19.5" x 20.0" x 9.0")
Weight Net Weight 6.8Kg (13.9lbs)
Gross Weight 9.5Kg (20.9lbs)
1 Pallet 40 Cartons
20’ Container 360 Sets
Packing
40’ Container 840 Sets
All specifications are subject to change without prior notice
f 17” SECURITY LCD DISPLAY f SPECIFICATION
S
X
-17
f FEATURES
High 1280 x 1024 SXGA resolution
Looping video inputs for multiple
connections
Auto termination
Quick signal-switching time (0.8 sec.)
Supports color and B/W picture
Automatic NTSC/PAL/SECAM scan system
selectable
Selectable signal source
PC compatible
Auto-adjustment for optimal setting
NeoV Optical Glass
TM
Distinctive metal alloy housing for added
strength
Kensington
security socket
V
ESA standard wall mount
