P/C: X17JV_X17J0_X17J1 Version 11.1, 20080606
Panel Panel Type TFT LCD
Panel Size 17.0" (432mm)
Max. Resolution SXGA 1280 x 1024
Pixel Pitch 0.264mm
Brightness 300cd/m
2
(Typical)
Contrast Ratio 3000:1 (DCR)
Viewing Angle (H/V) 160°/160° (Typical)
Display Color 16.7M
Response Time 3ms (GTG)
Frequency (H/V) H: 30kHz - 80kHz
V: 56Hz - 76Hz
Max. Pixel Clock 160MHz
Life Time 50,000hrs (Minimum)
Input Analog 15-Pin D-Sub
Digital 24-Pin DVI-D
S-Video 4-Pin Mini Din S-Video
CVBS CVBS Jack
Connector Power 3-Pin AC Plug
Thickness 3.0mm (0.18")
Reflection Rate <1%
Transmission Rate >96%
NeoV Optical
Glass
Hardness >6H (MOH’s Rating)
Tilt Tilt 0° ~ +15°
Mounting VESA FPMPMI Yes (100mm)
Regulation
Approval
Certifications &
Compliance
FCC, UL/CUL, TUV/S, CE,
BSMI, CB, ISO 13406-2,
Energy Star, GOST, WEEE,
RoHS
VESA DDC-2B, DPMS, DDC-CI
Power Power AC 100 - 240V, 50 - 60Hz
Consumption <48W (On)
<2W (Stand-by)
<1W (Off)
Dimensions Net (W x H x D) 408 x 398 x 175mm
(16.1" x 15.7" x 6.9")
Packing (W x H x D) 495 x 510 x 228mm
(19.5" x 20.0" x 9.0")
Weight Net Weight 6.8Kg (13.9lbs)
Gross Weight 9.5Kg (20.9lbs)
Packing 1 Pallet 40 Cartons
20’ Container 360 Sets
40’ Container 840 Sets
All specifications are subject to change without prior notice
f 17
”
LCD DISPLAY f SPECIFICATION
X-17
www.agneovo.com
Copyright © 2008 AG Neovo. All rights reserved.
The name AG Neovo is a trademark of Associated Industries China, Inc.
All other trademarks are the property of their respective owners.
f FEATURES
Distinctive metal housing for added
strength
NeoV Optical Glass
TM
Swift 3ms response time
High 3000:1 dynamic contrast ratio
DVI ready for high quality signal
S-Video and CVBS inputs
Hot key for preferred video mode: User,
Text, Movie, Game, and Graphic
Auto-adjustment for optimal settings
Kensington
security socket
VESA standard wall mount
Available colors: black, white
