AG Neovo X-19 Computer Monitor User Manual



P/C: X19MV_X19M1 Version 13.1, 20080530
Panel Panel Type TFT LCD
Panel Size 19" (483mm)
Max. Resolution SXGA 1280 x 1024
Pixel Pitch 0.294mm
Brightness 300cd/m
2
(Typical)
Contrast Ratio 3000:1 (DCR)
Surface Treatments Hard Coating (3H), Anti-glare
Treatment
Viewing Angle (H/V) 170°/160° (Typical)
Display Color 16.2M
Response Time 3ms (GTG)
Frequency (H/V) H: 30kHz - 80kHz
V: 56Hz - 75Hz
Max. Pixel Clock 135MHz
Life Time 50,000hrs (Typical)
Input Analog 15-Pin D-Sub
Digital 24-Pin DVI-D
S-Video 4-Pin Mini Din S-Video
CVBS CVBS Jack
Connector Power 3-Pin AC Plug
Thickness 3.0mm (0.18”)
Reflection Rate <1%
Transmission Rate >96%
NeoV Optical
Glass
Hardness >6H (MOH’s Rating)
Tilt Tilt 0° ~ +15°
Mounting VESA FPMPMI Yes (100mm)
Regulation
Approval
Certifications &
Compliance
FCC, UL/CUL, TUV/Baurt, CE,
BSMI, CB, ISO 13406-2,NOM,
Energy Star, GOST, WEEE,
RoHS
VESA DDC 1/2B, DPMS, DDC-CI
Power Power AC 100 – 240V, 50 – 60Hz
Consumption <48W (On)
<2W (Stand-by)
<1W (Off)
Dimensions Net (W x H x D) 444 x 419 x 175mm
(17.5” x 16.5” x 6.9”)
Packing (W x H x D) 540 x 525 x 228mm
(21.2” x 20.7” x 9.0”)
Weight Net Weight 7.9Kg (17.4lbs)
Gross Weight 10.7Kg (23.6lbs)
Packing 1 Pallet 32 Cartons
20’ Container 320 Sets
40’ Container 704 Sets
All specifications are subject to change without prior notice
f 19
LCD DISPLAY f SPECIFICATION
X-19
www.agneovo.com
Copyright © 2008 AG Neovo. All rights reserved.
The name AG Neovo is a trademark of Associated Industries China, Inc.
All other trademarks are the property of their respective owners.
f FEATURES
Distinctive metal housing for added
strength
NeoV Optical Glass
TM
Swift 3ms response time
Crisp 3000 dynamic contrast ratio
DVI ready for high quality signal
S-Video and CVBS inputs
Hot key for preferred video mode: User,
Text, Movie, Game, and Graphic
Auto-adjustment for optimal settings
Kensington
security socket
VESA standard wall mount
Available colors: black, white
