P/C: X20BV_X20B1_X20B0 Version 5.1, 20080530
Panel Panel Type TFT LCD
Panel Size 20.1" (511mm)
Max. Resolution UXGA 1600 x 1200
Pixel Pitch 0.255mm
Brightness 300cd/m
2
(Typical)
Contrast Ratio 1000:1 (Typical)
Surface Treatments Hard Coating (2H), Anti-glare
Treatment
Viewing Angle (H/V) 170°/170° (Typical)
Display Color 16.7M
Response Time 8ms (GTG)
Frequency (H/V) H: VGA Analog - 30kHz - 94kHz
H: VGA DVI - 30kHz - 80kHz
V: 50Hz - 75Hz
Max. Pixel Clock Analog: 203MHz, DVI: 165MHz
Life Time 50,000hrs (Typical)
Input Analog 15-Pin D-Sub
Digital 29-Pin DVI-D
S-Video 4-Pin Mini Din S-Video
CVBS CVBS Jack
Connector Power 3-Pin AC Plug
Thickness 3.0mm (0.18")
Reflection Rate <1%
Transmission Rate >96%
NeoV Optical
Glass
Hardness >6H (MOH’s Rating)
Tilt Tilt 0° ~ +15°
Mounting VESA FPMPMI Yes (100mm)
Regulation
Approval
Certifications &
Compliance
FCC, UL/CUL, TUV/BAURT, CE,
BSMI, CB, ISO 13406-2, GOST,
WEEE, RoHS
VESA DDC 2B, DPMS
Power Power AC 100 - 240V, 50 - 60Hz
Consumption <60W (On)
<4W (Stand-by)
<2W (Off)
Dimensions Net (W x H x D) 499 x 454 x 180mm
(19.7" x 17.9" x 7.1")
Packing (W x H x D) 594 x 261 x 570mm
(23.4" x 10.3" x 22.4")
Weight Net Weight 8.2Kg (18.2lbs)
Gross Weight 11.0Kg (24.2lbs)
Packing 1 Pallet 32 Cartons
20’ Container 320 Sets
40’ Container 640 Sets
All specifications are subject to change without prior notice
f 20.1
”
LCD DISPLAY f SPECIFICATION
X-20
www.agneovo.com
Copyright © 2007 AG Neovo. All rights reserved.
The name AG Neovo is a trademark of Associated Industries China, Inc.
All other trademarks are the property of their respective owners.
f FEATURES
Distinctive aluminum and magnesium alloy
housing for added strength
NeoV Optical Glass
TM
Swift 8ms response time
Super 1000 contrast ratio
High 300 brightness
170° wide viewing angles
DVI ready for high quality signal
Multiple video inputs
*
Cable organizer
Kensington
security socket
User-friendly OSD
