CAUTION The assemblies used in the multiple channel controller system are static
sensitive. Use anti-static techniques when performing the following
procedures. For example, wear an anti-static ground strap and work at a
station equipped with an anti-static mat.
CAUTION Do not disconnect or remove any boards from the mainframe unless the
mainframe is unplugged. Some boards contain devices that can be damaged
if the board is removed when the power is on. Several components, including
MOS devices, can be damaged by electrostatic discharge. Use a proper ESD
workstation when servicing this instrument.
NOTE It is assumed that the person performing the service tests understands how to
operate the multiple channel controller and the specified test equipment.
Equipment settings—other than those used for the multiple channel
controller—are stated in general terms. For example, a test might require
that a voltage of +5 Vdc be measured, however the Digital Multimeter
instructions as to mode and range would not be specified and the operator
would be expected to set that control and any other controls as required to
obtain a measurement. It is also assumed that the technician will select the
cables, adapters, and probes required to complete the test setups illustrated
in this section.
