85330A Multiple Channel Controller 5-7
Manual Operation
To View Custom Option Number (If Applicable)
To View Custom Option Number (If Applicable)
Some 85330As are equipped with custom driver s as required by the
customer. Pressing:
[Select Instr] then [More] the display will read:
Rev Opt? Test.
Click on Opt?
This presents the custom option number (if any) for the driver.
To Manually Send Trigger Pulses
To manually issue a trigger to the receiver (EVENT TRIGGER), RF or LO
source (TRIGGER IN):
1. Press:
[Select Instr] {85330A}
2. If the {TRIGGER} softkey does not appear, press
[Prev Menu] (until it does)
3. Press
{TRIGGER}, followed by:
{RCVR} to send a trigger to the receiver.
{SRC_1} to send a trigger to the RF source.
{SRC_2} to send a trigger to the LO source.
To Perform Service Functions
Service functions are located under the {85330) {→} {TEST} softkey menu. They
are not described in this chapter. Refer to “Verifying the Multiple Channel
Controller” on page 2-6 for more information.
