Allied Telesis www.alliedtelesis.com
Datasheet | integrated Multiservice Access Platform
iMAP Express 7112
integrated Multiservice Access Platform
The iMAP Express 7112 is a member of Allied
Telesyn’s iMAP family of IP-based integrated
multiservice access platforms. The 7112 is 1RU
and is optimal for delivery IP based services
including IP Video and high speed Internet.
Leveraging the same core technology as the
modular iMAP 9000 series of products, the 7112
is best suited for small density, cost-effective
deliv
er
y of ADSL2+ services
Small enough for remote cabinet or CO
deployments, the 7112 also offers optional AC
power kits that enable Service Providers or
Enterprise customer’s deployment flexibility -
CO, RT, MDU/MTU, Hospitality and Enterprise.
Dense ADSL2+ Delivery
The 7112 supports 48 ports of ADSL2+
(Annex A) from a single RU. Utilizing Allied
Telesyn’s ADSL2+ optimized amphenol
connectors, the 7112 ensures maximum Rate
vs. Reach performance.
Networking Capabilities
With support for Allied Telesyn’s Ethernet
Protection Switched Ring and RSTP, the 7112
offers numerous flexible network deployment
options – Rings,
point-to-point,
hub and spoke,
and mesh.
Whether using SFP based GbE or Fast
Ether
net,
the 7112 enab
les seamless integr
ation
into any Service Provider or Enterprise network.
Pay as you grow Scalability
Stacking capabilities ensures pay as you grow
Access with common netw
ork transport per
location. Using either Fast Ethernet or GbE, the
7112 units can be stacked together in either
daisy chain or ring fashion. Aggregate network
traffic can be transported from single or multiple
Fast Ethernet or GbE uplinks thereby minimizing
network transport costs.
Service Differentiation
QoS schemes for iMAP access solutions are
designed to ensure that application performance
and availability are not impacted with network
growth. Features such as IPDiffServ and 802.1p/q
enable tiered data services for both residential
and business/enterprise users.
Manageability
All iMAP access solutions are designed to be
managed and provisioned remotely using Allied
Telesyn's AlliedView™ Network Management
Software (NMS), a comprehensive network
management platform designed to increase
netw
or
k uptime and throughput while reducing
operating expense.
iMAP Express 7112 System
Configuration
1RU system (Fixed Configuration)
•
1 control module slot
• 48 ADSL2+ ports
iMAP Express 7112 Key Features
• Carrier-class IP/Ethernet access
• Video-optimiz
ed for IP Triple Play services
• IGMPv2 with Fast Joins/Leaves
• Environmentally-hardened
• Dual DC Power Feeds
• Optional AC Power kit
• Industry standard ADSL2+
• Network compatible with iMAP 9000 family
of products
• ETSI and
ANSI compliant
• Managed via AlliedView NMS
• Stacking f
or managed scaling
