TECHNICAL SPECIFICATIONS
• Cabinet Color: Black
• Panel: TFT Active Matrix LCD, VIS: 17" (43.2cm), Diagonal, Hard Coating (3H), Anti-glare Treatment
• Pixel Pitch: 0.264 mm x 0.264 mm
• Display Area: 338 mm x 270 mm
• Brightness: 300 cd/m² (typ)
• Contrast Ratio: 500:1 (typ)
• Response Time: 8 ms (typ)
• Viewing Angle: Horizontal: 170 Degrees (CR>5), Vertical: 170 Degrees (CR>5)
• Compatibility: VESA, SXGA, XGA,SVGA,VGA, Mac
®
Equipped With VGA Port
• Scanning Frequency: Horizontal: 30 K ~ 83 KHz, Vertical: 55 ~ 75 Hz
• Pixel Frequency: 135 MHz
• Maximum Resolution: 1280 x 1024 @ 75 Hz
• Recommended Resolution: 1280 x 1024 @ 60 Hz
• Resolutions Supported: 720 x 400 @ 70 Hz, 640 x 480 @ 60/66/72/75 Hz, 800 x 600 @ 56/60/72/75 Hz,
1024 x 768 @ 60/70/75 Hz, 1280 x 1024 @ 60/75 Hz
• Color: 16 M
• Signal Input: Video: 0.7 Vp-p, RGB Analog, Separate Sync: TTL Level, H/V Sync: Positive / Negative
• Connectors: RGB Signal: 15-pin D-sub (3-Pin Plug CEE22)
• Power Source: Universal 100 ~ 240 VAC, 50/60 Hz (Internal Power Supply)
• Power Consumption: 40 Watts ( Max.)
• Plug & Play: DDC2B
• EPA ENERGY STAR
®
: Yes
• User Control: Auto Adjust, Left/Brightness, Power, Right/Contrast, Menu
• OSD Function: Brightness, Contrast, Focus, Clock, H/V Position, Color, Temperature, Auto Config,
OSD H/V Position, OSD Timeout, Language, Information, Reset, Exit
• OSD Languages: English, French & Spanish
• Regulations: cULus, FCC, TUV/GS, TUV/S, CE, ISO 13406-2, TCO99, Windows® XP Logo
• Other Features: VESA 75 mm Wall Mount Compliant*, Kensington Security Slot
• Dimensions (W x H x D mm): Monitor: 380 x 390 x 180; Carton 435 x 456 x 134
• Dimensions (W x H x D inches): Monitor: 15.0 x 15.4 x 7.1; Carton: 17.1 x 18.0 x 5.3
• Monitor Dimensions w/o Base (WxHxD): 380 x 331 x 58 mm; 15.0 x 13.0 x 2.3
• Weight: 8.8 lbs (4.0 kg) Net, 11.0 lbs (5.0 kg) Gross
• Loading Qty w/pallet: 20' = 988 pcs.; 40' Std = 2052 pcs.
• Warranty: 3 Years
Monitor LCD 17” (LM760)
UPC Code 685417001385
Ultra-Thin LCD
Note: Specifications are subject to change without notice.
*Wall mount arm & bracket not included.
