TECHNICAL SPECIFICATIONS
• Cabinet Color: Silver & Black
•Panel: TFT Active Matrix LCD, VIS: 19" ( 48.0 cm ), Diagonal, Hard Coating (3 H),
Anti-glare Treatment
•Pixel Pitch: 0.294 mm x 0.294 mm
• Display Area: 376 mm x 301 mm
• Brightness: 270 cd/m2 (typ)
• Contrast Ratio: 500:1 (typ)
• Response Time: 4 ms GTG (typ)
• Viewing Angle: Horizontal: 150 Degrees, Vertical: 135 Degrees
• Compatibility: VESA, SXGA, XGA,SVGA,VGA, Mac® Equipped With VGA Port
• Scanning Frequency: Horizontal: 30 K ~ 83 KHz, Vertical: 55 ~ 75 Hz
•Pixel Frequency: 135 MHz
• Maximum Resolution: 1280 x 1024 @ 75 Hz
• Recommended Resolution: 1280x1024 @ 60 Hz
• Resolutions Supported: 720 x 400 @ 70 Hz, 640 x 480 @ 60/66/72/75Hz,
800 x 600 @ 56/60/72/75 Hz, 1024x768@60/70/75Hz, 1280 x 1024 @ 60/75 Hz
• Color: 16 M
• Analog Input: Video: 0.7 Vp-p, RGB Analog, Separate Sync: TTL Level,
H/V Sync: Positive / Negative
• Digital Input: DVI-D (TMDS)
• Connectors: Analog RGB Signal: 15-pin D-sub Male, DVI-D: 24-pin DVI-D,
Power: Coax Power Jack
• Power Source: Universal 100 ~ 240 VAC, 50/60 Hz (via External Power Brick)
• Power Consumption: 50 Watts ( Max. )
•Plug & Play: DDC2B
• User Control: Auto Adjust, Left/Brightness, Right/Contrast, Menu, Power
• OSD Languages: English, French & Spanish
• Regulations: cULus, FCC, CE, Windows® XP Logo
• Other Features: VESA 75 mm Wall Mount Compliant*, Kensington Security Slot,
Narrow Bezel, Dual Hinge Height Adjustment, Foldable Base, Tilt
•Weight: 13.2 lbs (6.0 kg) Net, 18.3 lbs (8.3 kg) Gross
• Loading Qty w/pallet: 20' = 780 pcs.; 40' Std = 1560 pcs.
•Warranty: 3 Years
Monitor LCD 19” (193P+)
UPC Code 685417005789
Ultra-Thin LCD
Note: Specifications are subject to change without notice.
*Wall mount arm & bracket not included.
