2016Vwa
Cabinet Color Black
Panel TFT Active Matrix LCD
VIS: 20" Widescreen, Diagonal
Hard Coating (3H), Anti-glare Treatment
Pixel Pitch
0.258mm x 0.258mm
Display Area
433.4x270.9mm
Brightness 300 cd/m2 (typ)
Contrast Ratio 3000:1 (dynamic)
Response Time 5ms (typ)
Viewing Angle Horizontal: 160 Degrees (CR>10)
Vertical: 160 Degrees (CR>10)
Compatibility VESA, WSXGA+, WXGA+, SXGA, XGA, SVGA,VGA
Mac® Equipped With Analog VGA Dsub or DVI Port
Scanning Frequency Horizontal: 30K~83KHz
Vertical: 55~75 Hz
Pixel Frequency 160MHz
Maximum Resolution
Recommended Resolution
Resolutions Supported
1680x1050x60H
z
1680x1050@60Hz
720x400@70Hz, 640x480@60/75Hz, 800x600@60/75Hz,
1024x768
@
60/70/75Hz, 1280x1024
@
60/75Hz, 1680x1050
@
60H
z
Color 16.7M
Signal Input Video: 0.7Vp-p, RGB Analog
Separate Sync: TTL Level
H/V Sync: Positive / Negative
Digital Input
DVI-D (TMDS) with HDCP*
Connectors
Analog RGB Signal: 15-pin D-sub Male
Digital Signal: 24-pin DVI-D
Power: (3-Pin Plug CEE22)
A
udio: 3.5m Stereo
Power Source
Universal 100~240VAC, 50/60Hz
Power Consumption
49Watts (Max)
Plug & Play DDC1/2B/CI
EPA ENERGY STAR® Yes
User Control
Source, AUTO Config,down,up,Menu,Powe
r
OSD Function
Brightness, Contrast, Focus, Clock, H/V Position, Color Temperature
(Cool,Warm,Normal,sRGB,RGBYCM), Sound Mode, Brightness, Contrast,
Hue, Saturation, H/V Position, OSD Setup(H/V position, Timeout,
Lan
g
ua
g
e
)
, Input Select, AUTO Confi
g
,Reset,Information
OSD Languages
En
g
lish, French, Spanish
Re
g
ulations
cULus, FCC, CE, Windows Vista
Built-in Speakers
1W x 2
Other Features
720p/1080i HD Compatible, VESA 100mm Wall Mount Compliant**,
Kensington Security Slot
Dimensions (WxHxD mm) Monitor: 472.5x380.9x210; Carton 537x450x150
Dimensions (WxHxD inches) Monitor: 18.6x15.0x8.3; Carton 21.1x17.7x5.9
Weight 11 lbs (5.0 kgs) Net
13.6 lbs (6.2 kgs) Gross
Loading Qty w/pallet 20' = 700 pcs.; 40' Std = 1540 pcs.
UPC Code 685417015580
A0907
Note: Specifications are subject to change without notice. *High-bandwidth Digital Content Protection: Enables viewing of High-Definition contents. **Wall mount arm & bracket not
included. Windows Vista and the Windows logo are trademarks or registere
