2219V1
Cabinet Color Piano Black Finish
Panel TFT Active Matrix LCD
22" Widescreen, Diagonal
548.3mm Viewable Image Size
Hard Coating (3H), Anti-glare Treatment
Pixel Pitch
0.277mm x 0.277mm
Display Area
465mm x 291mm
Brightness 300 cd/m2 (typ)
Contrast Ratio 3000:1 (dynamic)
Response Time 5ms (typ)
Viewing Angle Horizontal: 170 Degrees (CR>10)
Vertical: 160 Degrees (CR>10)
Compatibility VESA, WSXGA+, WXGA+, SXGA, XGA, SVGA,VGA
Mac® Equipped With Analog VGA Dsub or DVI Port
Scanning Frequency Horizontal: 30K~81KHz
Vertical: 50~75 Hz
Pixel Frequency 146MHz
Maximum Resolution
Recommended Resolution
Resolutions Supported
1680x1050x60Hz
1680x1050@60Hz
720x400@70Hz, 640x480@60, 67, 75Hz
800x600@56, 60, 72, 75Hz, 1024x768@60, 70, 75Hz,
1152x864@75Hz, 1280x1024@60, 75Hz, 1440x900@60, 75Hz,
1680x1050@60Hz
Color More than 16M
Signal Input Analog: 0.7Vp-p(standard), 75 OHM, Positive
Digital Input
DVI-D (TMDS) with HDCP*
Connectors
Analog RGB Signal: 15-pin D-sub Male
Digital Signal: 24-pin DVI-D
Power: (3-Pin Plug CEE22)
Power Source
Universal 100~240VAC, 50/60Hz
Power Consumption
49Watts ( Max. )
Plug & Play DDC 2B
EPA ENERGY STAR® Yes
User Control
Menu(1), Down/Brigtness, Up/Contrast, Confirm(2), Power
OSD Function
Auto Adjust, Contrast, Brightness, Color Adjust (sRGB, 9300K,
6500K, 5400K, User Color), Information, Manual Image Adjust (H-
Size, H/V Position, Fine Tune, Sharpness), Setup (Language,
Resolution Notice, OSD Setup), Memory Recall
OSD Languages
English, French, Spanish
Regulations
cULus, FCC, CE, Works with Windows Vista Logo, ROHS
Other Features
720p/1080i HD Compatible, VESA 100mm Wall Mount
Compliant**, Kensington Security Slot
Dimensions (WxHxD mm) Monitor: 517x409x216, Carton: 591x520x148
Dimensions (WxHxD inches) Monitor: 20.4x16.1x8.5, Carton: 23.3x20.5x5.8
Monitor Dimensions w/o Base (WxHxD) Monitor: 20.4x14.0x3.1
Weight 12.8 lbs (5.8 kgs) Net
16.9 lbs (7.7 kgs) Gross
Loading Qty w/pallet 20' = 540 pcs.; 40' Std = 1200 pcs.
UPC Code
685417021888
Note: Specifications are subject to change without notice. *High-bandwidth Digital Content Protection: Enables viewing of High-Definition contents. **Wall mount arm & bracket
not included. Windows Vista and the Windows logo are trademarks or registered trademarks of Microsoft Corporation in the United States and/or other countries.
A05/08
