416Va
Cabinet Color Black
Panel TFT Active Matrix LCD
VIS: 24" Widescreen, Diagonal
Pixel Pitch 0.27mm x 0.27mm
Brightness 400 cd/m2 (typ)
Contrast Ratio 3000:1 (dynamic)
Response Time 5ms (typ)
Viewing Angle Horizontal: 160 Degrees (CR>10)
Vertical: 160 Degrees (CR>10)
Compatibility PC/Windows, Mac® Equipped With Analog VGA Dsub or DVI Port
Scanning Frequency Horizontal: 30K~92KHz
Vertical: 60~85 Hz
Pixel Frequency 200MHz
Maximum Resolution
1920x1200x60Hz
Recommended Resolution
1920x1200x60Hz
Resolutions Supported
720x400@70Hz, 640x480@60/72/75Hz, 800x600@60/72/75Hz,
1024x768@60/70/75Hz, 1280x1024@60/70/75Hz,1440x900@60/75Hz,
1680x1050@/60Hz,1920x1200@60Hz
Color 16.7M
Signal Input Video: 0.7Vp-p, RGB Analog
Separate Sync: TTL Level
H/V Sync: Positive / Negative
Digital Input
DVI-D (TMDS) with HDCP*
Connectors
Analog RGB Signal: 15-pin D-sub Male
Digital Signal: 24-pin DVI-D
Power: (3-Pin Plug CEE22)
Power Source
Universal 90~264VAC, 50/60Hz
Power Consumption
49 Watts (Max)
Plug & Play DDC2B
EPA ENERGY STAR® Yes
User Control
Menu, Down/Brightness, Up/Contrast, Confirm, Power On/Off
OSD Function
Brightness, Contrast, Eco Mode,Gamma(1,2,3),DCR,Focus, Clock, H/V
Position, Color Temperature (Cool,Warm,Normal,sRGB,RGBYCM),
Color Boost(Full Enhance, Nature Skin, Green Field, Sky Blue, Auto
Detect, Demo) ,Picture Boost(Frame Size, Brightness, Contrast,
OSD Languages
English, French, Spanish
Regulations
cULus, FCC, CE, Certified for Windows Vista
Built-in Speakers
2W x 2
Other Features
720p/1080i HD Compatible, VESA 100mm Wall Mount Compliant**,
Kensington Security Slot
Dimensions (WxHxD mm) Monitor: 562x459x240, Carton: 657x527x226
Dimensions (WxHxD inches) Monitor: 22.1x18.1x9.4, Carton: 25.9x20.7x8.9
Weight Net: 16.5lbs (7.5kg)
Gross: 24.2lbs (11.0kg)
Loading Qty w/pallet (40'/20') 720 sets / 320 sets
UPC Code 685417017683
Note: Specifications are subject to change without notice. *High-bandwidth Digital Content Protection: Enables viewing of High-Definition contents. **Wall mount arm & bracket not
included. Windows Vista and the Windows logo are trademarks or registered trademarks of Microsoft Corporation in the United States and/or other countries. 5/08
