917Vw
917Vw
Cabinet Color
Glossy Black
Panel
TFT Active Matrix LCD
19" Widescreen, Diagonal
19" Viewable Image Size
Pixel Pitch 0.2835mm (H)x0.2835mm(V)
Display Area
408.2mmx255.2mm
Display Area
408.2mmx255.2mm
Brightness 300 cd/m2 (typ)
Contrast Ratio 3000:1 (DCR)
Response Time 5ms (typ)
Viewing Angle Horizontal: 160 Degrees (CR>10)
Vertical: 160 Degrees (CR>10)
Compatibility VESA VGA,XGA,SVGA, SXGA,WXGA
Mac® Equipped With Analog VGA Dsub & DVI Port
Mac® Equipped With Analog VGA Dsub & DVI Port
Scanning Frequency Horizontal: 36.5K~75.75KHz
Vertical: 55~75 Hz
Pixel Frequency 128MHz
Maximum Resolution
Recommended Resolution
Resolutions Supported
1440x900@60Hz
1440x900@60Hz
640x400@70,640x480@60/72/75,720x400@70,
800x600@56/60/72/75,832x624@75,1024x768@60/70/75,
800x600@56/60/72/75,832x624@75,1024x768@60/70/75,
1280x960@60, 1280x1024@60/75, 1440x900@60
Color 16.7 Million
Signal Input Video: 0.7Vp-p, RGB Analog
Separate Sync: TTL Level
H/V Sync: Positive / Negative
Digital Input
DVI-D (TMDS) with HDCP*
Connectors
Analog RGB Signal: 15-pin D-sub Male
Digital Signal: 24-pin DVI-D
Digital Signal: 24-pin DVI-D
Power: (3-Pin Plug CEE22)
Power Source
Universal 100~240VAC, 50/60Hz,
Power Consumption
37W Max
Plug & Play DDC 1/2B/CI
EPA ENERGY STAR® Yes
User Control
Eco/Up, Menu/Right, Auto/Down, Exit/Left, Power
OSD Function
Brightness, Contrast, Eco Mode,Gammar,DCR,H/V Position,
OSD Function
Brightness, Contrast, Eco Mode,Gammar,DCR,H/V Position,
Phase, Clock, Color Temperature, Color Boost,Picture Boost, OSD
Language Selection, Timeout, Menu Position, Auto Config, DDC-
CI, Reset, Information, Input Select
Language Supported
8 languages including English, French & Spanish
Compliance
cULus, FCC, CE, Certified for Windows Vista Logo, ROHS
Other Features
VESA 100mm Wall Mountable*, 5-scene Dynamic Color Boost,
Navigation Key
Other Features
Navigation Key
Dimensions (WxHxD mm) 439x358x204mm
Dimensions (WxHxD inches) 17.3x14.1x8.0in
Carton (WxHxD inches) 19.9x16.5x5.5in
Weight 8.36 Lbs (3.8kgs) Net
10.34 Lbs (4.7kgs) Gross
Loading Qty w/pallet 20' = 810 pcs.; 40' Std = 1890 pcs.
UPC Code
685417021086
UPC Code
685417021086
Note: Specifications are subject to change without notice. *Wall mount arm & bracket not included.
Windows Vista and the Windows logo are trademarks or registered trademarks of Microsoft Corporation in the United States and/or other countries. A01/08
