TECHNICAL SPECIFICATIONS
• CRT: Size (Diagonal): 17” (43.2cm) - FST
• Viewable Image Size (Diagonal): 16” (40.6cm)
• Pre-set Display Area: 300 x 230mm
• Signal Input: Video: 0.7Vp-p, RGB Analog
• Compatibility: VESA, XGA, SVGA, VGA
• Scan Frequency: Horizontal: 30K
˜
70KHz
• Pixel Frequency: 110MHz
• Maximum Resolution: 1280 x 1024 @ 60Hz
• Factory pre-set Mode: 6
• User Programmable Mode: 10
• Power Source: Universal 100 ~240 VAC, 50/60Hz
• Power Consumption: 120W (Max)
• EPA Energy Star®: Ye s
• Video Signal Connectors: 15 pin mini D-sub Male
• User Controls
• Front Panel: Power, UP, Down, Function Key
• Digital Control Function: Brightness, Contrast, H-size, H-center, V-size, V-center, Pinchusion, Trapezoid, Rotation, Degauss,
Recall
• Speaker Base: 7ELRA: 1W
• Plug & Play: VESA DDC1/2B
• Emissions Standard: MPRII
• Regulations: UL, FCC, FDA,CSA, TUV/GS, MPRII
• Weight: 7ELR: Net: 33lbs (15kg) - Gross: 38.5lbs (17.5kg)
• Dimensions (W x H x D): 7ELR: 410 x 402 x 420mm; 16.1 x 15.8 x 16.5 inches
• Loading Qty w/o pallet: 7ELR: 20’=220 pcs.; 40’ = 480pcs.; 40’ HQ= 598pcs.
• Video Cable Lenght: 6ft.
• Power Cord Lenght: 6ft.
• Warranty: 3 Years
Monitor CRT 17”
(7ELR and 7ELRA)
UPC Code: 7ELR: 685417487219; 7ELRA; 685417417216
Note: Specifications are subject to change without notice.
Standard CRT
