Attaching Paper Feed Unit TK1030
When installing multiple options, install the paper feed unit first.
• Before moving the machine, unplug the power cord from the outlet. If the cord is unplugged abruptly,
it could become damaged. Damaged plugs or cords can cause an electrical or fire hazard.
• When lifting the paper feed unit, hold the bottom of it, and then lift it slowly. Lifting it carelessly or
dropping it may cause an injury.
• The printer weighs about 17 kg (37.5 lb.). When lifting the machine, use the inset grips on both sides.
Otherwise the printer could break or cause injury if dropped.
• Do not slide out more than one paper tray at a time. Fully extending more than one full tray at a time
can cause the machine to topple over.
• Check the printer nameplate to confirm the model code.
• Before using the new paper feed unit, you must make settings in the printer driver.
1. Check the package contains the following:
Paper Feed Unit (including a paper tray)
ZKDX210J
2. Turn off the power of the printer, and then unplug the printer's power cable and the interface
cable.
