Specifying custom size paper for Tray 1 and the optional paper feed unit
• When printing on custom size paper, specify the paper size using the control panel or printer driver.
• The custom size paper selected using the printer driver overrides that selected using the control panel.
Do not make settings using the control panel if you have already made settings using the printer driver.
However, when printing with a printer driver other than the RPCS printer driver, you must configure
the settings using control panel.
• The following is the range of paper sizes that can be loaded in each type of the paper trays:
• Tray 1: 139.7 - 216 mm (5.5 - 8.5 in.) in width and 139.7 - 356 mm (5.5 - 14.01 in.) in length.
• Optional Paper Feed Unit (Tray 2, Tray 3): 139.7 - 216 mm (5.5 - 8.5 in.) in width and 160 -
356 mm (6.3 - 14.01 in.) in length.
• The printer cannot print from applications that do not support custom size paper.
1. Press the [Menu] key.
AUB051S
The [Menu] screen appears.
2. Press the [ ] or [ ] key to display [Paper Input], and then press the [ Enter] key.
3. Press the [ ] or [ ] key to display [Tray Paper Size], and then press the [ Enter] key.
4. Press the [ ] or [ ] key to display the target paper tray, and then press the [ Enter] key.
5. Press the [ ] or [ ] key to display [Custom Size], and then press the [ Enter] key.
6. Press the [ ] or [ ] key to set horizontal value, and then press the [ Enter] key.
5. Paper and Other Media
92
5
