Recess, Relax, and Revive in your PC-TV world!
At A Glance
z NTSC Analog TV
z ATSC Digital TV
z Clear QAM support (Digital Cable)
z Stereo sound
z High Definition (HDTV) quality
support up to 1080i/720p
z 32/64-Bit driver support
z Windows XP/Vista MCE fully
compliant by S/W encoder
z Windows® Vista Premium logo
Certificated
z Enjoy 10-foot UI with AVer
MediaCenter software
z PCI Express interface
z Low profile form factor
z Real-time H.264 recording support
z Multi-card support
SPECIFICATIONS
Input Signal
z 75 Ω TV Antenna Input
z S-Video
z Composite input
z Audio L/R
z
FM input
AVerTV Bravo Hybrid PCI-E adopts the latest innovation ideas of Clear
QAM tuning. Users can simply connect the coaxial Cable input (analog or
digital) into the AVerTV Bravo Hybrid PCI-E to watch unencrypted digital
contents as well as Schedule Recording and TimeShift functions right
under their finger tips.
The AVerTV Bravo Hybrid PCI-E is a digital terrestrial (ATSC)/analog
(NTSC) TV receiver module. Users can get access of over-the-air digital
TV programs in MPEG-2 sound and image quality on the PC. By the
advanced H.264 recording compression technology, users can record
favorite TV shows into 320x240 resolution and play on iPod!
Furthermore, users can connect AV equipment, such as camcorder,
VCR, or game console to the TV card for audio/video capturing.
AVer MediaCenter is the bundled software of AVerTV Bravo Hybrid
PCI-E. AVer MediaCenter takes PC-TV software to a new level. By using
AVer MediaCenter and purchasing the additional remote control*, users
can enjoy watching TV from 10-foot distance, like with normal TV at
home! Users can easily manipulate all entertainment such as TV shows,
video clips, music, and photos. The greatest bonus is that it supports
dual tuners or multiple TV tuner cards. Users can watch several
live
programs simultaneously on one monitor (depend on CPU loading).
* Order Optional AVer MediaCenter remote control from AVerMedia Technologies,
Inc. USA e-Store
COMPARISON TABLE
Product Name AVerTV Combo PCI-E
(M780)
AVerTV Bravo Hybrid
PCI-E (H788)
Card Type PCI Express PCI Express
Signal of Reception NTSC TV
ATSC TV
NTSC TV
ATSC TV
S/W Application AVer MediaCenter AVer MediaCenter
Tuner Dual Single
QAM Support YES YES
64 Bit Driver Support YES YES
Prima
r
y
release: September 19, 200
7
