Adapters:
Antenna: LW6000A: Diversity patch;
LW6001A: External detachable
dipole antenna with attached
37" (94-cm) cable and RP-SMA
connector;
LW6002A: 6-dBi directional
high-gain antenna
Distance (Maximum): 328 ft. (100 m)
Frequency Band: 2.4000–2.4835 GHz
Modulation: OFDM with BPSK,
QPSK, 16QAM, 64QAM (11g),
BPSK, QPSK, CCK (11b)
Operating System: Compatible with
all major operating systems;
Drivers included for Windows
®
98
SE/Me/XP, Windows 2000, and
Windows NT
®
Security: 64-/128-bit WEP Data
Encryption, WPA (TKIP with IEEE
802.1x), and AES
Speed: 54, 48, 36, 24, 18, 12, 11, 9, 6,
5.5, 2, 1 Mbps with auto fallback
Standards: IEEE 802.11b, IEEE
802.11g
CE Approval: Yes
Interface: LW6000A: 32-bit cardbus;
LW6001A: 32-bit PCI V.2.2/2.1;
LW6002A: USB 2.0
Connectors: LW6000A: (1) PCMCIA
slot;
LW6001A: (1) RP-SMA antenna
connector;
LW6002A: (1) mini USB F
Indicators: LEDs: LW6000A,
LW6001A: (1) TX/RX, (1) Link;
LW6002A: (1) Power, (1) Link
Power: From the interface
Size: LW6000A: 0.3"H x 4.6"W x 2.1"D
(0.8 x 11.7 x 5.3 cm);
LW6001A: 0.9"H x 4.8"W x 5.3"D
(2.3 x 12.2 x 13.5 cm);
LW6002A: 4.5"H x 3"W x 3.4"D
(11.4 x 7.6 x 8.6 cm)
Access Point:
Antenna: (1) RP-SMA detachable
2.2-dBm dipole antenna
CPU: ADMtek 5120 175-MHz MIPS
R4000
Distance (Maximum): 328 ft. (100 m)
with 2.2-dBm dipole antenna
Security: 64-/128-/158-bit WEP
encryption, WPA (TKIP with
IEEE 802.1x), and AES
Memory: 2-MB Flash, 8-MB DRAM
Operating System: Compatible with
all major operating systems;
Drivers included for Windows 98
SE/Me/XP, Windows 2000, and
Linux
Speed: Wireless: 54, 48, 36, 24, 18,
12, 11, 9, 6, 5.5, 2, 1 Mbps with
auto fallback;
Ethernet: 10/100 Mbps,
autosensing
Standards: IEEE 802.11b, IEEE
802.11g, IEEE 802.3, IEEE 802.3u,
IEEE 802.1x
Transmit Power: 18 dBm
CE Approval: Yes
Connectors: (5) RJ-45 LAN
Indicators: LEDs: (1) PWR,
(1) WLAN, (5) LAN, (5) 10/100
Power: 115-VAC, 60-Hz external
power adapter
Size: 1.2"H x 5"W x 3.6"D
(3 x 12.7 x 9.1 cm)
Router:
Antenna: (1) RP-SMA detachable
2.2-dBm dipole antenna
CPU: ADMtek 5120 175-MHz MIPS
Distance (Maximum): 328 ft. (100 m)
Security: 64-/128-/158-bit WEP
encryption, WPA (TKIP with
IEEE 802.1x), and AES
Memory: 2-MB Flash, 16-MB DRAM
Operating System: Compatible with
all major operating systems;
Drivers included for Windows 98
SE/Me/XP, Windows 2000, and
Linux
Protocols Supported: Dynamic IP,
Static IP, PPPoE, PPTP, L2TP,
Telstra Big Pond, IEEE 802.1x
Speed: Wireless: 54, 48, 36, 24, 18,
12, 11, 9, 6, 5.5, 2, 1 Mbps with
auto fallback;
Ethernet: 10/100 Mbps,
autosensing
Standards: IEEE 802.11b, IEEE
802.11g, IEEE 802.3, IEEE 802.3u
Transmit Power: 18 dBm
CE Approval: Yes
Connectors: (1) RJ-45 WAN,
(4) RJ-45 LAN
Indicators: LEDs: (1) PWR,
(1) WLAN, (1) WAN 10/100M,
(1) WAN LNK/ACT, (4) LAN
10/100M, (4) LAN LNK/ACT
Power: 115-VAC, 60-Hz external
power adapter
Size: 1.2"H x 7.4"W x 4.2"D
(3 x 18.8 x 10.7 cm)
Antennas:
Beam Width: LW6200A: H360, V15;
LW6201A: H30, V30
Cable Length: LW6200A: 19.7"
(50 cm);
LW6201A: 11.8" (30 cm)
Distance (Maximum): LW6200A:
0.62 mi. (1 km);
LW6201A: 1.86 mi. (3 km)
Frequency Band: 2.4000–2.5 GHz
Gain: LW6200A: 8 dBi;
LW6201A: 14 dBi
Impedance: 50 ohms
Lightning Protection: DC ground
Survival Wind Speed: 111.8 mi./hr.
(180 km/hr.)
Connectors: (1) N F
Size: LW6200A: 0.7"W x 24.8"L
(1.8 x 63 cm);
LW6201A: 9.4"H x 9.4"W x 2.8"D
(23.9 x 23.9 x 7.1 cm)
