CEN-WAP-ABG-1G
One-Gang 802.11a/b/g Wireless Access Point
quickstart guide
1
For details, refer to the latest version of the
CEN-WAP-ABG-1G Operations & Installation Guide, Doc. 6695.
QUICKSTART DOC. 6693A (2021162) 08.08
www.crestron.com
888.273.7876
©2008 Specifications subject to
change without notice.
201.767.3400
CEN-WAP-ABG-1G
Introduction
1
Installing the Access Point
2
3
The CEN-WAP-ABG-1G is a wireless access point that supports IEEE
802.11a/b/g Wi-Fi technology. In addition, the CEN-WAP-ABG-1G
supports the IEEE 802.3af Power over Ethernet (PoE) industry
standard. Using PoE technology, the CEN-WAP-ABG-1G receives
both power and data by way of a single Ethernet cable.
Shipped with uniquely configured network identification settings,
the CEN-WAP-ABG-1G provides a secure wireless connection for
Crestron
®
Wi-Fi touchpanels. As a result, additional configuration of
the access point is not required as part of the installation.
To accommodate applications in which customized configuration
settings are desired, the access point also provides a Web-based
configuration utility that offers a setup wizard as well as additional
network management settings.
Front View Rear View
LED Indicators (Front of Unit)
Before installing the access point, note the following:
● The access point must be installed in a temperature-controlled
environment ranging from 32° to 104° F (0° to 40° C).
● Do not remove the sticker that is attached to the front of the access
point. You will need the information provided on the sticker if you
perform the steps in section of this guide.
MOUNTING
Mount the access point into a wall or into a rack as appropriate for
your installation.
Wall Mounting: For the best possible range, it is recommended
that you mount the access point as high as possible and away from
metal objects.
1. Using the two supplied Phillips pan head screws, mount the
access point into a one-gang low-voltage bracket or electrical box.
The recommended depth of the electrical box is a minimum of
2.5 inches. The maximum voltage of the access point is 48 VDC.
2. Attach the desired Decora
®
faceplate (not supplied).
Wall Mounting
(Low-Voltage Bracket Shown)
Rack Mounting: The access point mounts horizontally into a 19-inch
rack and occupies 1U (1.75 inches) of rack space. For the best
possible range, it is recommended that you mount the unit into the
topmost rack space.
To mount the access point, use the Middle Atlantic HBL1-722243
rack mount panel. For ordering information, contact Middle Atlantic
Products, Inc. (http://www.middleatlantic.com).
CONNECTIONS
Power and Network Connection, Rear Ethernet Port: Depending on
the equipment you have purchased, connect the access point to a
Crestron PoE injector, a Crestron PoE switch, or a third-party 802.3af
compliant power source.
Connection to Crestron PoE
Injector (Part No. PWE-4803RU).
For information about the PoE
injector, refer to the latest
version of the PWE-4803RU
PoE Injector Installation
Guide (Doc. 6712),
which is available from
the Crestron website
(www.crestron.com/manuals).
Connection to Crestron PoE
Switch.
Up to four access points can
connect to the CEN-SW-POE-5
switch. For additional information
about the switch, refer to the
latest version of the
CEN-SW-POE-5 Switch
Installation Guide (Doc. 6694).
Connection to Third-Party 802.3af Power Source. Refer to the documentation
supplied with the third-party device for installation information.
Antenna Connection: Network Connection,
Screw the supplied Front Ethernet Port
antenna onto the (Optional): Connect
access point. local wired Ethernet
equipment to the front
Ethernet port.
INDICATOR DESCRIPTION
LAN Solid green indicates that the rear Ethernet port has established a valid Ethernet connection.
Flashing green indicates Ethernet activity through the rear Ethernet port.
Wi-Fi Solid green indicates that a wireless network connection has been established.
Flashing green indicates wireless data activity.
Amber indicates that the front Ethernet port has established a 100 Mbps Ethernet connection.
Solid green indicates that the front Ethernet port has established a valid Ethernet connection.
Flashing green indicates Ethernet activity through the front Ethernet port.
Antenna
Connector
Front
Ethernet
Port
Rear
Ethernet
Port, PoE
AMBER
LED
GREEN
LED
(CEN-SW-POE-5 Shown)
3
#6-32 x ¾”
Phillips Pan Head
Screws
All brand names, product names and trademarks
are the property of their respective owners.
Injector Power LED
Green: PoE device is connected.
Flashing red: Non-PoE device is
connected.
Amber: No device is connected.
