NEW PASSWORD COMPLETE
ESC : QUIT ENTER : COMPLETE
d. The “ CONSOLE ON/OFF “ function is used to manage users. If you select “ CONSOLE
ON “, it means that any user can use the console. If you select “ CONSOLE OFF “(factory
default OFF state), it means that any user will not be allowed to use the console unless
you enter the password. When you enter the password already and authenticate with the
GFC 1716A, the CONSOLE will be set to ON. After you finish using GFC 1716A,
please don’t forget to set CONSOLE ON state to OFF state. Additionally, if current CONSOLE
state is set to ON, and you reset GFC 1716A, the CONSOLE will be set to the OFF
state.
e.
When you finish the setting up of PC name and exiting the OSD setting mode, you will find
the PC name appears at the up-left corner of monitor. You can use the “ESC” key to
clear the PC name if it's no longer required.
Ɓ
SYSTEM 02102
f. To return the OSD to its factory default value, you can execute “SCROLL
LOCK”, “SCROLL LOCK”, “R” keys in this order. The Seven segment LEDs on the front
panel will be flashed during the refresh process.
ROM REFLASH
When the OSD has been returned to its default setting, the seven segment LEDs on the
front panel will stop flashing
