Back to Contents Page
Hinge Covers
Dell™Latitude™E6510ServiceManual
Removing the Hinge Covers
1. Follow the procedures in Before Working Inside Your Computer.
2. Remove the battery.
3. Remove the access panel.
4. Remove the screws that secure the right hinge cover to the computer.
5. Remove the screws that secure the left hinge cover to the computer.
6. Slide the left and right hinge covers toward the back of the computer and remove them from the computer.
Replacing the Hinge Covers
To replace the hinge covers, perform the above steps in reverse order.
Back to Contents Page
WARNING: Before working inside your computer, read the safety information that shipped with your computer. For additional safety best
practices information, see the Regulatory Compliance Homepage at www.dell.com/regulatory_compliance.
NOTE: YoumayneedtoinstallAdobe™FlashPlayer™fromAdobe.com in order to view the illustrations below.
