E218c1
Cabinet Color Black Cabinet with Polished/Glossy Black Bezel
Panel TFT Active Matrix LCD
VIS: 22" (55.9cm) Widescreen, Diagonal
Hard Coating (3H), Anti-glare Treatment
Pixel Pitch
0.282mm x 0.282mm
Display Area
474mm x 296mm
Brightness 300 cd/m2 (typ)
Contrast Ratio 700:1 (typ)
Response Time 5ms (typ)
Viewing Angle Horizontal: 170 Degrees (CR>10)
Vertical: 160 Degrees (CR>10)
Compatibility VESA, WSXGA+, WXGA+, SXGA, XGA, SVGA,VGA
Mac® Equipped With Analog VGA Dsub or DVI Port
Scanning Frequency Horizontal: 30K~80KHz
Vertical: 50~75 Hz
Pixel Frequency 146MHz
Maximum Resolution
Recommended Resolution
Resolutions Supported
1680x1050x60Hz
1680x1050@60Hz
720x400@70Hz, 640x480@60, 67, 75Hz
800x600@56, 60, 72, 75Hz, 848x480@60Hz
1024x768@60, 70, 75Hz, 1152x864@75Hz
1280x720@60Hz, 1280x960@60Hz, 1280x768@60, 75Hz
1280x1024@60, 75Hz, 1360x768@60Hz, 1440x900@60, 75Hz
1440x900@60,
Color 16M
Signal Input Video: 0.7Vp-p, RGB Analog
Separate Sync: TTL Level
H/V Sync: Positive / Negative
Digital Input
DVI-D (TMDS) with HDCP*
Connectors
Analog RGB Signal: 15-pin D-sub Male
Digital Signal: 24-pin DVI-D
Power: (3-Pin Plug CEE22)
Audio: 3.5mm Stereo
Headphone: 3.5mm mini jack
Microphone: 3.5mm mini jack
USB: 1x upstream & 3x downstream
Power Source
Universal 90~264VAC, 50/60Hz
Power Consumption
58Watts (Max)
Plug & Play DDC2B
EPA ENERGY STAR® Yes
User Control
Menu, Down/Brightness, Up/Contrast, Confirm, Power On/Off
OSD Function
Auto Adjust, Contrast, Brightness, Input Select (Analog, Digital), Audio
Adjust (Volume, Mute), Color Adjust (9300K, 6500K, 5400K, User),
Information (H/V Frequency, Resolution, Pixel Clock, Serial Number, Model
Number, Manual Image Adjust (Horizontal Size)
OSD Languages
English, French, Spanish
Regulations
cULus, FCC, CE, Certified for Windows Vista Logo
Built-in Speakers
Total 5W
Other Features
Built-in 1.3MP Webcam & Microphone
Echo Cancellation
720p/1080i HD Compatible
Height Adjustment, Swivel Stand
USB 2.0 Hub
Application Software
VESA 100mm Wall Mount Compliant**
Kensington Security Slot
Dimensions (WxHxD mm) Monitor: 518.4x403.4x216.0; Carton: 565x522x150
Dimensions (WxHxD inches) Monitor: 20.4x15.9x8.5; Carton: 22.2x20.6x5.9
Weight 16.5 lbs (7.5 kgs) Net, 12.7 lbs (5.8 kgs) w/o base
21.36 lbs (9.7 kgs) Gross
Loading Qty w/pallet 40' Std = 704
UPC Code
685417103188
E0707
Note: Specifications are subject to change without notice. *High-bandwidth Digital Content Protection: Enables viewing of High-Definition contents. **Wall mount arm & bracket not included.
