Epson FX-2190 and Accessories
Product Code Description UPC Code
C11C526001 Epson FX-2190 Impact Printer 0 10343 84806 1
S015335 Ribbon Cartridge 0 10343 60510 7
C800211 Additional Push/Pull Tractor Unit 0 10343 80011 3
C806391 Single Bin Cut Sheet Feeder 0 10343 80022 9
C806401 High Capacity Cut Sheet Feeder 0 10343 80023 6
C823051 Serial Interface Board 0 10343 07003 5
C823071 32KB Serial Interface Board 0 10343 07004 2
C823121 LocalTalk Interface Board 0 10343 81167 6
C823141 Coax Interface Board 0 10343 80016 8
C823151 Twinax Interface Board 0 10343 80017 5
C823452 Bidirectional Parallel Interface Board 0 10343 81245 1
C12C823912 EpsonNet Multiprotocol 10/100 Base-TX 0 10343 83773 7
Type-B Ethernet Print Server
Ordering Information
6
Printer Specifications
Printing Method
9-pin, serial impact dot matrix
Print Direction
Bidirectional logic seeking for text and graphics printing. Unidirectional text
or graphics printing can be selected using software commands.
Print Speed
Ultra Speed Draft 680 cps (12 cpi)
566 cps (10 cpi)
High Speed Draft 559 cps (10 cpi)
Draft 419 cps (10 cpi)
Near Letter Quality 104 cps (10 cpi)
(Note: Normal print speed is achieved when printer safety cover is
fully closed)
Character Sets
13 character tables
13 international character sets
Resident Bitmapped Fonts
Ultra Speed Draft 10, 12 cpi
High Speed Draft 10, 12, 15, 17, 20 cpi
Draft 10, 12, 15, 17, 20 cpi
NLQ (Roman/Sans Serif) 10, 12, 15, 17, 20 cpi, proportional
Column Width
10 cpi 136
12 cpi 163
15 cpi 204
17 cpi 233
20 cpi 272
Bar Code Fonts
EAN-13, EAN-8, Interleaved 2 of 5, UPC-A, UPC-E, Code 39, Code 128,
POSTNET, Codabar (NW-7), Industrial 2 of 5, Matrix 2 of 5
Formatting
1/6
"
or programmable in 1/432
"
increments
Line Spacing: 6 lines per inch default
(8 lpi option available on FX-2190 Okidata Mode only)
Paper Feed Mechanism
Feeding method Friction feed (front, rear)
Push tractor (front, rear)
Pull tractor (front, bottom, rear)
Push and pull tractor*(front, rear)
Cut sheet feeder (optional)
Roll paper holder (optional)
Paper Feed Speed
62 millisecond per 1/6
"
5
"
per second continuous feed
Paper Path
Manual insertion Front or rear in, top out
Cut sheet feeder Rear in, top out
Tractor Front, rear or bottom in, top out
Pull/push tractor Front or rear in, top out
Input Buffer
128KB
Software Drivers
Windows 95, 98, Me, 2000, XP and NT 4.0
Interface
Bidirectional Parallel (IEEE 1284 Nibble Mode supported)
USB 1.1
Type-B slot for optional interface cards
Printer Language
Epson ESC/P
IBM PPDS
Okidata Microline (FX-2190 Okidata Mode only)
Paper Handling
Forms: continuous multipart, original plus 5 carbonless copies,
1 + 6 copies with pull tractor, maximum thickness .018"
Width
Single sheets 3.9" to 16.5"
Continuous 4.0" to 16.0"
Cut-sheet feeder 7.2" to 16.5"
Length
Single sheets 3.9" to 14.3"
Continuous 4.0" to 22.0"
Cut-sheet feeder 10.1" to 14.0"
No. 6 envelopes 6.5" x 3.6"
No. 10 envelopes 9.5" x 4.1"
Labels 2.5" x 0.94" (minimum)
Roll paper 8.5" width
Sound Level
55 dBA (ISO 7779 pattern)
Power Requirements
Rated voltage 100 to 240V
Input voltage range 90 to 264V
Rated frequency range 50 to 60 Hz
Input frequency range 49.5 to 60.5 Hz
Physical Dimensions
Height 6.1"
Width 23.2"
Depth 13.8"
Weight 21.2 lb
Control Panel Functions
Font, pitch, pause, tear off, bin selection, line feed, form feed, load, eject,
micro adjust, top-of-form adjustment, panel lockout, reset, menu, default
setting selection
Reliability
Total print volume 52 million lines (except print head)
MTBF 20,000 POH (25% duty cycle)
Print head life 400 million characters at 14 dots/character
Ribbon life 12 million characters at 14 dots/character
Warranty
Three-year limited warranty in the U.S. and Canada
*Additional tractor unit required
A
p
in
t
sof
Win
print
or th
The
h
and 1
12 mi
low c
o
depen
Comp
and o
dema
year
lead
e
Specifications and terms are subject to change without notice. Epson and Epson ESC/P are registered trademarks of Seiko Epson Corporation. Epson Remote Configuration Manager is a trademark
of Epson America, Inc. All other product and brand names are trademarks and/or registered trademarks of their respective companies. Epson disclaims any and all rights in these marks.
© Copyright 2003 Epson America, Inc. CPD-16781 8/03 5K CL
Epson America, Inc.
3840 Kilroy Airport Way, Long Beach, CA 90806
Epson Canada, Ltd.
3771 Victoria Park Avenue, Toronto, Ontario M1W 3Z5
5
Packing Specifications
Epson FX-2190
Single carton dimensions (L x W x H) 28" x 18.3" x 10.7"
Single carton weight 24.5 lb
20 ft container 231
Pallet quantity 11
40 ft container 483
Pallet quantity 23
