Introduction
HP docking solutions include a range of convenient expansion solutions that easily connect to your HP Business Notebook and enable
connectivity to a range of peripherals. Create an ideal desktop computing environment using comfort-focused docking stations and
stands that provide port replication, cable management, and future expandability.
These docking stations feature the proprietary HP Docking Station Cable Lock, in addition to an industry standard notebook lock slot.
The HP Docking Station Cable Lock (AU656AA) gives you three locking options: lock the docking station only (which also prevents
access to the advanced docking station's drive bay); lock both the docking station and the notebook; or physically secure the docking
station to a stationary object using the security cable tab.
NOTE:
Check the compatibility sections below for a list of products supported by these docking stations. Due to technology changes,
some notebook models may be supported by different docking station solutions. Please also refer to your notebook's QuickSpecs for
individual compatible product information. All docking stations only support single-link DVI-D.
Models
HP 2012 90W Docking Station
A7E32AA
HP 2012 230W Docking Station
A7E34AA
HP 2012 120W Advanced Docking Station
A7E36AA
HP 2012 230W Advanced Docking Station
A7E38AA
HP Docking Station Cable Lock
AU656AA
Compatibility
HP 2012 Docking Stations and HP Advanced Docking Stations are compatible with HP ProBook b-Series Notebook PCs, HP EliteBook
8xxx p Series Notebook PCs, and HP EliteBook 8xxx w Series Mobile Workstations.
The HP 2012 230W Docking Station and Advanced Docking Station are compatible with the HP EliteBook 8xxx p Series Notebook PCs
and w Series Mobile Workstations. The HP Docking Station Cable Lock (AU656AA#XXX) is compatible with the docking stations.
NOTE:
Some notebook models do not support these docking features. Docking capability for these models is provided by the HP
3005pr USB 3.0 Port Replicator (H1L08AA) and HP 2005pr USB 2.0 Port Replicator (H1L07AA).
NOTE: Not all models are available in all regions.
Service and support
One-year limited warranty. Additional support is available 24 hours a day, seven days a week by phone as well as online support forms.
NOTE:
Certain restrictions and exclusions apply. Consult the HP Customer Support Center for details.
QuickSpecs
HP 2012 Docking Stations and HP 2012 Advanced
Docking Stations for HP Business Notebooks
Overview
DA - 14356 Worldwide — Version 3 — December 13, 2012
Page 1
