E-44
RECORDING
Adjusting audio recording level
The analog audio recording level can be adjusted on this unit. There are two adjustment methods,
selected using A.REC VR.MD.: DV in the AUDIO Menu screen.
The audio recording level can be set to the initial setting value. (UNITY mode)
Memo
Audio input level from the IEEE1394 terminal cannot be adjusted.
Set “Q, S” KEY FUNC. in the SYSTEM [1/2] Menu screen to VAR/RECV.
Select an adjustment method using A.REC VR.MD.: DV in the AUDIO Menu screen.
BOTH :The audio recording level for both CH1 and CH2 are adjusted simultaneously.
INDEPEND : The audio recording level for CH1 and CH2 are adjusted separately.
Hide the Menu screen.
This can be adjusted in the STOP or REC mode. Watching the audio level indicator
on the front panel, adjust so that the far right LED is turned off.
Increasing the recording level
Press the R button while holding down the Q or S button. The
audio recording level for both CH1 and CH2 increases.
Decreasing the recording level
Press the P button while holding down the Q or S button. The
audio recording level for CH1 and CH2 decreases.
Settings
Adjusting audio recording level
Simultaneously adjusting both channels (BOTH)
Adjustment buttons Audio level indicator
E-45
Adjusting the CH1 channel
Press the R or P button while holding down the Q button.
Press the R button to increase the recording level.
Press the P button to decrease the recording level.
Adjusting the CH2 channel
Press the R or P button while holding down the S button.
Press the R button to increase the recording level.
Press the P button to decrease the recording level.
To set the audio recording level to the initial setting
value, press the Q button and S button simulta-
neously.
•The audio recording level is fixed to the initial setting value.
Adjusting each channel separately (INDEPEND)
Adjusting the audio recording level to the initial setting value
(UNITY mode)
