E-72
MENU SCREENS
Description of the Menu screens (continued)
AUDIO Menu Screen
Item Setting Description
AUDIO MODE
: DV
(0300)
32K (00)
E48 K (01)
For selecting the audio sampling frequency for analog audio
recording.
32 K :Records at 32 kHz. Up to four channels of recording tracks
are available, but this unit only records onto two of these
channels.
48 K :
Records at 48 kHz. It records in the 2-channel stereo mode.
Memo
Setting this item is not required for DV signal or HDV signal input.
The audio mode will match the input signal.
A.OUTPUT: DV
(0301)
ECH1/2 (00)
MIX (01)
CH3/4 (02)
Select the audio channel for output signals from the AUDIO OUT
terminal or PHONES terminal. Select the following audio choices.
(In DV format mode only)
•Playback audio of tapes recorded in 32kHz audio mode
• EE audio of DV signal input in 32kHz audio mode
CH1/2:Outputs audio of channels CH1 and CH2.
MIX :Outputs mixed sound of CH1 and CH3 to the CH1/3 ter-
minal, and the mixed sound of CH2 and CH4 to the CH2/
4 terminal.
CH3/4:Outputs audio of channels CH3 and CH4.
A.OUT AT
SRH: DV
(0302)
OFF (00)
EON (01)
For enabling/disabling audio output from this AUDIO OUT termi-
nal during slow playback or searches. (In DV format mode only)
OFF:Output off.
ON :Output on.
Memo
When playing back an HDV format tape, search audio is not out-
put.
AUDIO OUT
LEV
(0303)
E–20 dB (00)
–12 dB (01)
For selecting the level for playback audio output.
–20 dB :Usually, this setting is used.
–12 dB :Select here to reduce the analog sound output level. It
will be reduced by 8 dB.
V.FADE: DV
(0304)
OFF (00)
EON (01)
For enabling/disabling the V.FADE function, which reduces sound
noise in playback that is produced at jointed parts of recording.
OFF :V.FADE function disabled.
ON :V.FADE function enabled.
Memo
When playing back an HDV format tape, the V. FADE function is
unavailable.
A REC VR.MD.:
DV
(0305)
EBOTH (00)
INDEPEND (01)
Select audio recording level adjustment method.
Select whether to adjust both channels simultaneously, or to
adjust each channel separately.
BOTH :Simultaneously adjusts both channels.
INDEPEND:Adjusts both channels separately.
PAGE BACK For returning to the TOP Menu screen.
E-73
VIDEO Menu Screen
Item Setting Description
SET UP [60]: DV
(0400)
OFF (00)
EON (01)
For enabling/disabling the application of setups to analog video
signals (composite, Y/C and SD component).
(During recording and playback) (Only for U model)
OFF :Does not apply setups.
ON :Applies setups.
Memo
The application of setups on playback or recorded video signals
must match the setting of SET UP. Otherwise, if dubbing is
repeatedly performed, the hue and brightness of the video may
not appear normal.
MONITOR
SELECT
(0401)
EHDMI[A] (00)
OUT FRMT (01)
Select the video format to output from the HDMI OUT terminal
and the COMPONENT OUT terminal.
HDMI[A] : Automatically outputs video to match the video for-
mat for the connected HDMI monitor.
OUT FRMT: Outputs video format set using menu items OUT
FORMAT [60] or OUT FORMAT [50].
OUT FORMAT
[60]
(0402)
ENATIVE (00)
480I (01)
480P (02)
1080l (03)
720P (04)
Sets the video output format to output from COMPONENT OUT
terminal or HDMI OUT terminal during HDV/DV signal input or
playback. (Cross converter video)
*During HDV signal input or playback of a tape recorded with
HDV signals, this menu item is available when 60/50 SEL in
the SYSTEM [2/2] Menu screen is set to 60.
During DV signal input or playback of a tape recorded with DV
signals, this menu item applies to the U model.
NATIVE :Outputs IEEE1394 terminal video input format or the
video format recorded on a tape, without conversion.
480I :Video with 480 effective scanlines, 60-field interlace
scan (SD video)
480P :Video with 480 effective scanlines, 60-frame progres-
sive scan (SD video)
1080I :Video with 1080 effective scanlines, 60-field interlace
scan (HD video)
720P :Video with 720 effective scanlines, 60-frame progres-
sive scan (HD video)
Memo
z This menu item is valid when the MONITOR SELECT menu
item is set to OUT FRMT.
It is also valid when an HDMI monitor is not in use while the
MONITOR SELECT menu is set to HDMI[A].
z During analog signal input, the SD video (480i) is output from
the COMPONENT OUT terminal and HDMI OUT terminal,
regardless of the menu settings.
