E-78
MENU SCREENS
Description of the Menu screens (continued)
DISPLAY Menu screen
Item Setting Description
DISPLAY
(0600)
OFF (00)
EON (01)
AUTO (02)
For turning on/off on-screen status display on the monitor con-
nected to the VIDEO OUT terminal.
OFF :
No on-screen status display. Only video is displayed.
ON :Always shows on-screen status display.
AUTO :Shows on-screen status display for about 4 sec-
onds during mode changes.
COUNTER
POSI.
(0601)
E
LOWER-R (00)
LOWER-L (01)
PPER-R (02)
UPPER-L (03)
CENTER (04)
For selecting the counter display position (CTL counter, time code
and user’s bit) of the monitor.
LOWER-R : Lower right
LOWER-L : Lower left
UPPER-R :Upper right
UPPER-L :Upper left
CENTER :Center
TIME CODE
(0602)
OFF (00)
EON (01)
For enabling/disabling the time code display on the monitor.
OFF :No display
ON :Display
VTR MODE
(0603)
OFF (00)
EON (01)
For enabling/disabling the VCR mode on the monitor.
OFF :No display
ON :Display
TAPE REMAIN
(0604)
OFF (00)
EON (01)
For enabling/disabling the display of the remaining time of the
tape on the monitor.
OFF :No display
ON :Display
TIME/DATE
(0605)
OFF (00)
TIME (01)
DATE (02)
E
DATE+TM (03)
For enabling/disabling the time/date display on the monitor and
selecting the display format.
OFF :No display
TIME :Time display only
DATE :Date display only
DATE+TM :Date/Time display
A/V INFO.
(0606)
OFF (00)
EON (01)
Select whether to display video/audio information on the monitor.
OFF :No display
ON :Display
DATE STYLE
(0607)
YY/MM/DD (00)
MM/DD/YY (01)
DD/MM/YY (02)
For selecting the date display format.
YY/MM/DD :Year/Month/Day
MM/DD/YY :Month/Day/Year (Set when shipping U model)
DD/MM/YY :Day/Month/Year (Set when shipping E model)
TIME STYLE
(0608)
12HOUR (00)
E24HOUR (01)
For selecting the display style of time.
12HOUR : 12-hour mode
24HOUR : 24-hour mode
PAGE BACK For returning to the TOP Menu screen.
E-79
OTHERS
Warning display
When an error occurs, BR-HD50 automatically self-diagnoses the cause and displays an error-coded
warning message on the monitor.
If BR-HD50 is not in good order, or if an operation error has occurred, an alarm display will be shown on
the monitor.
Alarm display (Displayed regardless of the DISPLAY mode)
•For alarm displays resulting from operation errors, refer to page 24.
3DNIV2KCH–1/2 6PSM0
W
ARNING 7001
DRUM MOTOR FAILURE
06/14/05 STANDBY
-
OFF
11:20:00 TCR 02:00:00:0
0
3MINDV 2K CH–1 / 2 SP 60
HEAD CLEANING REQUIRED!
06/10/05 STANDBY
-
OFF
11:20:00 TCR 02:00:00:00
Alarm displayWarning display
Display Status Action
LOW VOLTAGE The DC power voltage is low.
BR-HD50 will eventually go into the OPERATE
OFF mode if operation is continued.
Check the power voltage.
HEAD CLEANING
REQUIRED!
The video head is dirty. (This message is dis-
played when the DISPLAY mode is ON or
AUTO.) If the head is clogged, it will be
detected and the alarm message will be dis-
played in the PLAYBACK mode. The display
disappears when the cassette is ejected or the
head gets cleared of clog.
The message will also disappear when the
head cleaning tape is loaded.
Clean it with a JVC head-
cleaning tape. (XPage 9)
If the message persists
despite cleaning, it could be
due to bad recording condi-
tion, defective tape or head
lifespan.
OVER HEATING! The internal temperature of BR-HD50 has
exceeded the stated value.
Disconnect the power and
place BR-HD50 in a cool
place. If this message is dis-
played again, the unit may
have been damaged. In such
a case, consult your JVC
authorized dealer.
UNPLUG MAIN
POWER, PLUG
BACK IN AFTER A
WHILE
This is a system error that occurs when the
power is turned on. The OPERATE indicator on
BR-HD50 blinks in green. The unit will not
accept any operation commands.
Unplug the power cord from
the power outlet and wait for
some time before plugging it
back in.
