E-84
OTHERS
Specifications
General
Power requirements
:DC 12 V W (from provided
AC adapter)
Power consumption
:DC 12 V W 26.4 W 2.2 A
Usable tape
:Standard/ mini DV cassette tape
Tape speed :18.8 mm/s
Record/play time
:276 minutes (with LA-DV276PRO
tape)
63 minutes (with M-DV63PROHD
tape)
External dimension
:212 mm (W) × 88 mm (H) ×
327 mm (D) (Excluding pro-
truding parts)
Weight :Approx. 3.9 k
(Not including AC Adapter)
Allowable operating temperature
:5°C to 40°C
Allowable storage temperature
:–20°C to 60°C
Allowable operating humidity
:30% RH to 80% RH
Allowable storage humidity
:85% RH or less
Video
Recording format
:720/24p, 720/25p, 720/30p,
576/50p, 480/60p
(BR-HD50U/HD50E),
480/60i (BR-HD50U),
576/50i (BR-HD50E)
Video format :
[HDV]
Video signal recording format
:HDV720p format, 8-bit, 19.7
Mbps
Compression :MPEG-2 video (profile &
level: MP@H-14)
[DV]
Video signal recording format
:DV format, 8-bit, 25 Mbps
Compression :DVformat, 4:1:1 (NTSC)/
4:2:0 (PAL)
Audio
[HDV]
Audio signal recording format
:MPEG1 Audio Layer II
[DV]
Audio signal recording format
:16-bit (locked audio), 48 kHz
PCM for 2 channels or 12-bit,
32 kHz PCM for 4 channels
Connectors
Video
[HDV]
Video outputs
Analog component
Y :1.0 V (p-p), 75 : (BNC)
P
B/PR :0.7 V (p-p), 75 : (BNC)
[DV]
Video inputs
Analog composite:1.0 V (p-p), 75 : (BNC)
Analog Y/C
Y :1.0 V (p-p), 75 :
C :0.286 V (NTSC)/0.3 V (PAL)
(p-p), 75 : (4-pin)
Video outputs
Analog composiye
:1.0 V (p-p), 75 : (BNC)
Analog Y/C
Y :1.0 V (p-p), 75 :
C :0.286 V (NTSC)/0.3 V (PAL)
(p-p), 75 : (4-pin)
Analog component
Y :1.0 V (p-p), 75 : (BNC)
P
B/PR :0.7 V (p-p), 75 : (BNC)
Audio
Audio inputs
Line :–8 dBs, 10 k: unbalanced
(RCA)
Audio outputs
Line
:–8 dBs, 1 k
:
unbalanced (RCA)
Headphones :– f to – 15 dBs, 8 : (Stereo
mini Jack)
HDMI output :Type A (19-pin)
IEEE1394 interface
:6-pin
RS-422 interface :D-sub-9pin
Serial remote interface
:Mini jack
AC adapter
Input :AC 100 V - 240 V D,
50 Hz/60 Hz 1.0 A - 0.5 A
Output :DC 12 V W 3.5 A
Accessories
AC adapter (AA-G30) .................................... × 1
Power cord (for BR-HD50U) ......................... × 1
Power cord (for BR-HD50E) ......................... × 2
Ferrite core (for IEEE1394 cable) ................. × 1
Ferrite core (for DC cord) .............................. × 1
E-85
External dimensions (Unit: mm)
212
327
88
For improvement, the specifications and external appearance may be changed without prior notice.
˝
