This Remote is capable of transmitting two control
codes; one set to respond to A code control signals and
another set to respond to B code control signals.
This Remote control is preset to send A code signals
because your VCR is initially set to respond to A code
signals. You can easily modify your VCR and the Remote
to respond to B code signals.
When using two JVC VCRs, set two VCRs and their
Remotes to different codes, so that you can operate these
VCRs separately.
1
Set remote operation mode
Set the VCR/TV/CABLE/DBS selector to “VCR”.
2
Set remote control code for Remote
1 Press and hold A/B.
2 Press the Number key “2”.
3 Press STOP ( 7 ), and release A/B.
3
Turn off VCR
Press POWER on the VCR.
4
Check remote control code for VCR
Press PLAY (3) on the VCR for more than 5
seconds.
● The code currently set appears on the front
display panel.
5
Turn on VCR
Press POWER on the Remote.
● The code transmitted from the Remote blinks
for a few seconds on the front display panel.
● After the code disappears on the front display
panel, make sure that the VCR is turned on by
pressing POWER on the Remote.
● To set the Remote and the VCR back to A code
control signals, repeat the same procedure as
shown above except pressing the Number key
“1” in step 2.
To control two VCRs with the same Remote
You can control two JVC VCRs by switching the remote
control code for the Remote between A and B
(੬␣ step␣ 2), keeping two VCRs to different control codes.
● Press the Number key “1” for A code control signals
and the Number key “2” for B code control signals. (To
change only the remote control code for the Remote,
DO NOT perform steps 3 to 5.)
Changing
Remote Control
Code
(Ex.) To set Remote to B code:
Press in succession
Hold
down
Release
STOP
ABC
A/B
2
123
456
7
89
0
VCR TV CABLE/DBS
2 –1, 3
5
2
2 –3
2 –2
NOTE:
When "POWER SAVE MODE" is set to "ON" , you can not
change the remote control code. Before changing the code, set
"POWER SAVE MODE" to "OFF" (
੬
pg. 56).
