Inside view
1 Feed module — provides smooth document feeding and
separation of various sizes, thicknesses and textures of
documents.
2 Imaging guides — for optimum image quality, keep the imaging
guides clean. There are two guides - one upper and one lower.
3 Rollers — provides smooth document feeding of various sizes,
thicknesses and textures of documents.
4 Paper present sensor — detects the presence of documents in
the paper path during feeding and imaging.
Rear view
1 Power port — connects the power cord to the device.
2 Main power switch — turns the device on and off.
3 Soft Start button — restarts the device (warm boot).
4 Ethernet port — connects the device to the network.
5 Fuse — for Service personnel only.
