Digital Solar Window Thermometer
Model 306-605
FEATURES
Clear Functional Design
Maximum and Minimum Values with
Auto Reset
Clock
Easy Removal for Cleaning
Automatic Backlight for Easy reading in
the Dark
Weather Resistant
2
DISPLAY (see Fig. 1)
A. Battery Indicator
B. AM/PM for 12 hour time
C. Time
D. DST (Daylight Savings Time) Indicator
E. Temperature
F. MIN Temperature
G. MAX Temperature
Fig.1
3
BUTTONS (see Fig. 2)
H. MODE Button
I. + 1 Button
J. +/- 1hr Button
K. ECO Slide
HOUSING (see Fig. 3)
L. Temperature Probe
M. Battery Compartment
N. Solar Panel
HOLDER (see Fig. 4)
O. Holder
Fig.2
Fig.3
Fig.4
4
QUICK INSTALLATION GUIDE
Thoroughly clean the window where the thermometer holder will be attached.
Remove the thermometer holder from the thermometer by sliding it towards the bottom of
the thermometer.
Pull off the protection foil on the display
Attach the thermometer holder to the outside of the window with the enclosed adhesive
tape. (Be sure to mount with the frame “bar” down.)
Check that the bottom bar is in place to “catch” the thermometer, then hang the
thermometer on the holder by sliding it down into the holder.
Note: The thermometer is fragile. . When you mount or remove the thermometer, avoid action
that would bend or pull on it.
SETUP INSTRUCTIONS
Remove the thermometer holder from the thermometer by sliding it towards the bottom of
the thermometer.
Pull off the protection foil on the display.
Open the battery compartment with a small Phillips screwdriver.
Insert the NiMh AAA battery (included) on the left. Make sure to observe the correct
polarity.
Insert the alkaline AAA battery (included) on the right. Make sure to observe the correct
polarity.
Ensure the NiMh Battery is Charged: The 1.2V NiMh rechargeable battery for the backlight is
not
fully charged when shipped. For maximum efficiency it is recommended to either:
a) charge the battery fully (place thermometer outside on a sunny day) before first use
b) Recharge the NiMh battery in an appropriate NiMh-capable battery charger.
After the rechargeable battery is charged:
Re-insert the NiMh battery (if a charger was used).
Replace the battery compartment cover.
