DESCRIPTION OF PARTS (FIG. 1)
A. LCD DISPLAY
B. IN/OUT SWITCH
C. VENT HOLES
D. WALL MOUNT HOLE
E. °C/°F SWITCH , H-HOUR BUTTON,
M-MINUTE BUTTON
F. STAND
G. BATTERY DOOR
H. OUTDOOR SENSOR PROBE
BATTERY
The Thermometer uses 1 x UM-4 (AAA)
battery (1.5V D.C.)
Follow these steps to install or replace the
battery:
1. Slide the battery door in the direction
of the arrow.
2. Insert the battery as indicated by the
polarity symbols (+ and -) marked inside
the battery compartment.
3. Replace the battery door.
CLOCK
Press H or M to change the Hour or Minute.
Press and hold to enter fast-setting mode.
SELECT INDOOR / OUTDOOR
TEMPERATURE
The IN/OUT switch on the front of the
Themo-Clock selects between indoor /
outdoor temperature. Slide to the IN
position for indoor temperature. Slide to
the OUT position for outdoor temperature.
SELECT MEASUREMENT UNIT
The slide switch on the back of unit selects
between degree Celsius and Fahrenheit.
To select Celsius units, set the slide to °C.
To select Fahrenheit units, set the slide
switch to °F.
RESET UNIT
If your Thermo-Clock doesn’t operate
property, take out the battery from the unit
for 4 to 5 seconds, then reinstall the
battery.
POSITION THE OUTDOOR SENSOR
PROBE (FIG. 2)
I. SCREW
J. WIRE ATTACHMENT
Follow these steps to secure the external
probe.
1. Drive a screw (not included) into the
wall at the location you choose for the
sensor.
2. Hang the outdoor sensor’s wire
attachment loop onto the screw .
3. Route the outdoor sensor’s cord
(3 meters) through the window.
INTRODUCTION
• Thank you for your purchase of this
Digital Thermo-Clock.
•Your Digital Thermo-Clock is an
example of superior design and
craftsmanship.
• In order to optimize its functions, be
sure to read this instruction manual
carefully before use.
• Keep this manual handy for future
reference.
FEATURES
• Digital LCD Thermometer with Clock.
•Temperature/Clock alternate display
function at 3 seconds cycle.
• User selectable indoor or outdoor
temperature measurement.
• User selectable °C or °F temperature
units of measure.
•Wall mounting and table standing
feature.
DIGITAL INDOOR / OUTDOOR
THERMO CLOCK
Model : NAW881EXT
