CF-30Mk2 CF-30FTSAXAM
Operating System Microsoft
®
Windows
®
Vista™ Business (XP Downgrade DVD in box)
CPU Intel
®
Centrino
®
Core 2 Duo Processor L7500 (1.60 GHz, 4 MB
*1
L2 cache, 800 MHz FSB)
Chipset Intel
®
GM965
Memory
*1
1GB (1 GB Max.) DDR2 SDRAM
Video Memory
*1*2
UMA (384 MB Max.)
Hard Disk Drive
*3
80 GB SATA
Display Method 13.3 XGA type (TFT) with Touchscreen 1000cd/m
2
Wireless LAN Intel PRO / Wireless 4965 ABG (802.11 a + b + g)
Bluetooth Version 2.0+EDR
LAN IEEE 802.3 10Base-T, IEEE 802.3u 100Base-TX, IEEE 802.3ab 1000Base-T (10/100/1000)
Modem Data: 56 kbps (V.92) FAX: 14.4 kbps
Sound WAVE and MIDI playback, Monaural speaker, Intel
®
High Definition Audio subsystem support
Security Chip TPM (TCG V1.2 compliant)
Card Slot PC Card Type I or Type II x 1 (3.3 V: 400 mA, 5 V: 400 mA)
ExpressCard ExpressCard/34 or ExpressCard/54 x 1
HCSD Memory Card
*8
x 1, Data transfer rate = 8 MB per second
*9
Smart Card
*10
x 1 Optional
RAM Module Slot 200-pin, 1.8 V, SO-DIMM, DDR2 SDRAM, PC2-4200 Compliant
Interface USB port (4-pin, USB 2.0) x 3, Serial Port (Dsub 9-pin male), Modem port (RJ-11), LAN port
(RJ-45), External display port (Mini Dsub 15-pin female), Expansion Bus Connector (Dedicated
80-pin female), External Antenna Connector (Dedicated 50 Ω coaxial connector), IEEE 1394a
Interface Connector (4-pin x 1), Microphone Jack (Miniature jack, 3.5 DIA, Monaural), Headphone
Jack (Miniature jack, 3.5 DIA, Impedance 32 Ω, Output Power 4 mW × 2)
Keyboard / Pointing Device 87 keys / Touch Pad / Touchscreen (Anti-Reflection, Stylus (included) touch capable)
Power Supply AC adaptor, DC adaptor or Battery pack
AC Adaptor Input: 100 V to 240 V AC, 50 Hz/60 Hz, Output: 15.6 V DC, 5.0 A
Battery Pack Li-ion 10.65 V, 8.55 Ah
Operating Time
*11
Approx. 4hours at set to maxim brightness setting(typ:1000nit)
Approx. 5hours (typ:500nit) to Approx. 8hours at BIOS default setting
*12
Approx. 8hours
*13
Charging Time
*11
(Power on) Approx. 8.5Hours
Rated Power Consumption Approx.45W
Physical Dimensions (W × H × D)
(including the carrying handle)
302 mm × 67.5 - 69.5 mm × 292 mm
Weight
(including the carrying handle)
Approx. 3.8 kg
Operating Environment Temperature: 5 °C to 35 °C
Humidity: 30% to 80% RH (No condensation)
Storage Environment Temperature: -20 °C to 60 °C
Humidity: 30% to 90% RH (No condensation)
Utility Programs DMI Viewer, Microsoft
®
Windows
®
Media Player 10, Adobe Reader, PC Information Viewer,
SD Utility, Icon Enlarger, Loupe Utility, Intel
®
Matrix Storage Manager, Intel
®
PROSet/Wireless
Software, Bluetooth Stack for Windows
®
by TOSHIBA , Wireless Switch Utility, Hotkey
Settings, Battery Recalibration Utility, Panasonic Hand Writing, Infineon TPM Professional
Package
*14
, Recover Pro
™
6
*14
Setup Utility, Hard Disk Data Erase Utility
*15
, PC-Diagnostic Utility
*1 1GB = 1,000MB.
*2 A segment of the main memory is allotted automatically depending on the computer’s operating status. The size of the Video Memory cannot be set by the user.
*3 1GB = 1,000,000,000 bytes. Your operating system or some application software will report as fewer GB.
*4 A 16,777,216 color display is achieved by using the dithering function.
*5 Maximum resolution depends on the specifications of the external display.
*8 Operation has been tested and confirmed using Panasonic SD Memory Cards with a capacity of up to 32 GB.
The transfer rate using the SD Memory Card slot on this computer is 8 MB per second. (This is a theoretical value, and differs from actual speeds.)
The transfer rate is 8 MB per second even if you use an SD Memory Card that supports high-speed transfer rates.
Operation on other SD equipment is not guaranteed.
This computer is not compatible with MultiMediaCards.
*9 Theoretical value and not the actual speed. The transfer rate does not become higher even if you use a card that supports the higher transfer rate.
*10 Only for model with Smart Card slot.
*11 Varies depending on the usage conditions.
*12 Measured using BatteryMark. Version 4.0.1 (LCD brightness: Maximum - Minimum at BIOS default setting).
*13 Measured using MobileMark. 2002 (LCD brightness: 60 cd/m2).
*14 You need to install to use the feature.
*15 The Product Recovery DVD-ROM is required.
Panasonic reserves the right to change design and specifications with out notice.
www.toughbook.com.au
Panasonic recommends Microsoft
®
Windows Vista
™
Business.
