DIAG-MENU OPERATIONS
71
The unit’s system software version display, hour meter displays for the drum motor, rotating heads, etc. (for number of hours
used can be viewed on the DIAG menu.
To transfer from a regular mode to the DIAG mode:
! Set the unit to the jog mode.
• Remember that the mode cannot be transferred in the shuttle mode.
@ Press the DIAG (SHIFT+REC) buttons. (This cannot be done by remote control.)
The hour meter displays appear on the VTR1 and VTR2 monitor screens.
# Turn the dial to move to an item.
Turn it clockwise (FWD) to move down and counterclockwise (REV) to move up.
To display the version:
! Press the FF button on the VTR2 while holding down the SHIFT button.
The display changes from hour meter to version.
To return from the DIAG mode to the normal mode:
Press the DIAG (SHIFT+REC) buttons.
DIAG-MENU HOUR METER
<VTR-2>
10000H
10000H
10000H
10000T
10000H
10000H
10000T
H00
H01
H02
H03
H11
H12
H13
OPERATION
DRUM RUN
TAPE RUN
THREADING
DRUM RUN r
TAPE RUN r
THREADING r
DIAG-MENU
<VTR-2>
Ver<1.00-00>
Ver<1.00-00>
Ver<1.06-00>
Ver<1.00-00>
Ver<1.00-00>
DISPLAY
AV-SYSCON
SBC
CYLINDER
REEL
END
Version display
(Above display is version for
VTR2.)
Hour meter display
