APPENDIX A
SPECIFICATIONS
Transmission: Asynchronous and Synchronous
Clocking: Internal, external or derived from receive
signal
Distance: 3 miles maximum (4.8km)
1184 Data Rates: Asynchronous: 0 to 19.2 kbps
Synchronous: 4.8, 9.6, 14.4, 19.2, 28.8,
32.0, 56.0, 64.0, 128.0 kbps
1185 Data Rates: Asynchronous: 2.4 to 38.4 kbps
Synchronous: 2.4, 9.6, 14.4, 28.8, 38.4,
56.0, 64.0, 72.0, 128.0, 144.0, 192.0, 256.0
kbps
Handshaking: Software (XON/XOFF) or hardware
(RTS/CTS). Both modes available at all times.
Connectors: Either ST or SMA
Link Budget: 12 dB (62.5 micron), 8 dB (50.0 micron)
Diagnostics: V.54 Compliant - Local Analog Loopback
and Remote Digital Loopback bit error rate
pattern
Fiber Modes: Single 50 or 62.5 micron core, multi-mode
fiber optic cable
LED Indicators TD, RD, RTS, DTR, ER, NS and TM
Interface
Modules: EIA RS-232/CCITT V.24, RS-232/530,
CCITT V.35, X.21, Ethernet Bridge and
G.703
Power: 115/230 VAC (switch selectable), 50/60 Hz,
5 Watts; 85V - 256 VAC, 50/60 Hz
(universal input option); 48 VDC (option). 5
Watts.
Regulatory FCC part 15 Class A
Compliance: UL 1950, EN60950
89/336/EEC, 73/23/EEC
IEC 825 Class 1 equipment
Temperature
Range: 0-50°C (32-122°F)
Altitude: 0-15,000 feet
Humidity: 5 to 95% non-condensing
Dimensions: 7.3” x 6.6” x 1.62” ( mm x mm x mm)
Weight: 2.02 lbs. 1.0 Kg
17
APPENDIX B
FACTORY REPLACEMENT PARTS
AND ACCESSORIES
Patton Model #
Description
IM1/A...............................V.24 with DB25F
IM1/B...............................RS422/RS530 with DB25F
IM1/C...............................V.35 with M34F
IM1/D...............................X.21 with DB15F
IM1/E...............................V.35 with DB25F
IM1/F ...............................G.703 with RJ45
IM1/G...............................High Speed Async w/DB-25F
IM1/I ................................Ethernet Bridge
0805US ...........................American Power Cord
0805EUR.........................European Power Cord CEE 7
0805UK ...........................United Kingdom Power Cord
0805AUS.........................Australia/New Zealand Power Cord
0805DEN.........................Denmark Power Cord
0805FR............................France/Belgium Power Cord
0805IN.............................India Power Cord
0805IS.............................Israel Power Cord
0805JAP..........................Japan Power Cord
0805SW...........................Switzerland Power Cord
07M1090SVC..................Service Manual
18
