Philips 7620 Microcassette Recorder User Manual



Playback
Press and hold the PLAY/PAUSE/REMAIN button during normal
playback to display the remaining duration of the current file.
1. Normal Playback
1. Normal Playback
1. Press the FOLDER/REPEAT button to select the
desired folder (A, B, C, or D).
If you do not select a folder, the last folder to
which you recorded will be played.
2. Press the PLAY/PAUSE/REMAIN button to start
playback. The green LED will light and the
duration of the recording will be displayed
(Figure 10).
3. Press the PLAY/PAUSE/REMAIN button again
to pause playback.
4. Press the PLAY/PAUSE/REMAIN button again
to resume playback.
5. Press the STOP/DEL button during Playback or
Pause to stop playback.
2. Low-speed Playback
2. Low-speed Playback
1. Press the REPEAT/FOLDER button to select the desired folder
(A, B, C, or D). If you do not select a folder, the folder that you
recorded to or played last will be played.
2. Press and hold the PLAY/PAUSE/REMAIN button for
approximately 2 seconds to start low-speed playback. The green
LED will light and the duration of the recording will be displayed.
3. Press the PLAY/PAUSE/REMAIN button briefly again during
low-speed playback to pause.
4. In Pause, press and hold the PLAY/PAUSE/REMAIN button for
approximately 2 seconds to resume low-speed playback or press the
button briefly to start normal playback.
5. Press the STOP/DEL button during Playback or Pause to stop
playback.
3. Search
3. Search
1. Press and hold the NEXT button or BACK button for at
least a half a second during Playback.
Playback stops and the time on the LCD increases or decreases
rapidly.
2. Release the button when you wish to start playback.
3. The search will stop when the end of the current file is reached if
you press and hold the NEXT button or when the beginning
of the current file is reached if you press and hold the
BACK button .
4. Playback of other Files
4. Playback of other Files
1. To switch to the next or previous file, press the NEXT button
or BACK button briefly during Playback or Pause.
2. To navigate through all files, press and hold the NEXT button
or BACK button during Stop to switch to the desired file.
Release the button to play the displayed file.
Figure 10
English DeutschFrançaisNederlandsItalianoEspañol
DeutschFrançaisNederlandsItalianoEspañol
êÛÒÒÍËÈ
êÛÒÒÍËÈ
5. Repeat
5. Repeat
Repeat Section
1. Press the FOLDER/REPEAT button where you
want to start the section repeat. The starting
point is set and the indicator flashes
(Figure 11).
2. While is flashing, press the FOLDER/REPEAT
button again where you want to stop repetition.
The indicator lights continuously and the
selected section will be repeated 10 times
(Figure 12).
3. Press STOP/DEL to stop playback.
Repeat File
1. Press and hold the FOLDER/REPEAT button
during Playback.
2. The indicator will appear and the current
file will be repeated 9 times (Figure 13).
3. Press STOP/DEL to stop playback.
RepeatFolder
1. Press and hold the FOLDER/REPEAT button
during Playback.
2. When appears on the LCD (Figure 13), press and hold the
FOLDER/REPEAT button again.
3. appears on the LCD and all files in the
current folder will be repeated 10 times
(Figure 14).
4. Press STOP/DEL to stop playback.
Menu
1. Mic Recording Sensitivity
1. Mic Recording Sensitivity
The factory default is high-sensitivity mode.
1. Press the MENU/HOLD button once during
Record/Playback/Stop (Figure 16).
2. Press the NEXT button or the
BACK button .
3. The mode will toggle between low-sensitivity
mode (LO SENSE) and high-sensitivity mode
(HI SENSE) (Figures 15 and 16).
4. Press the PLAY/PAUSE/REMAIN or the
STOP/DEL button to select the displayed mode.
5. The previous operation will be resumed with the
selected mode.
Note: HI SENSE: Recommended for recording in a
quiet environment.
LO SENSE: Recommended for recording in a noisy
environment. Put the microphone close to the sound
source.
Figure 11
Figure 12
Figure 13
Figure 14
Figure 16
Figure 15
