SPECIFICATIONS
For information on power requirements, power consumption, dimensions, weight, and other specifications that are
common to all features of the machine, refer to page 6-2 of "Operation manual (for printer operation and general
information)".
Maximum original size 11"x17"
Two-sided originals Possible
Optical resolution 600dpi
Output modes 1bit/pixel
Halftone processing Error dispersion (200/300/400/600dpi)
File format*
1
File type: PDF/TIFF/TIFF-F
Compression mode: NONE/MH (G3)/MMR (G4)
Scan destinations Scan to FTP
Scan to Desktop
Scan to E-mail, Internet-Fax
Management system Uses built-in Web server
Web browser Internet Explorer 4.0 or later, Netscape Navigator 4.0 or later
Network protocol TCP/IP, UDP/IP
LAN connectivity 10Base-T/100Base-TX
Supported mail system Mail servers supporting SMTP
Number of destinations 500 maximum*
2
Number of senders 20 maximum
Output resolution
Destination type
E-mail/FTP Broadcast transmission Broadcast transmission
Resolution
(E-mail/Internet-Fax) (Fax/E-mail/Internet-Fax)
STANDARD 200x200dpi 200x100dpi 203.2x97.8dpi
(8x3.85line/mm)
FINE 300x300dpi 200x200dpi 203.2x195.6dpi
(8x7.7line/mm)
SUPER FINE 400x400dpi 200x400dpi 203.2x391dpi
(8x15.4line/mm)
ULTRA FINE 600x600dpi 400x400dpi 406.4x391dpi
(16x15.4line/mm)
*1 The file format for Internet-Fax is automatically set to TIFF-F. Compression mode selections are MH (G3) and
MMR (G4).
*2 A total of 500 destinations can be stored, including E-mail, FTP, Desktop, Internet-Fax, and Group destinations.
Among these, a combined total of 100 Scan to FTP and Desktop destinations can be stored.
Some discrepancies may exist in the illustrations and content due to improvements to the machine.
