– 106 –
The componants identified by
shading and mark
are criti-
cal for safety.
Replace only with part number
specified.
KP-41S5/41S5B/41S5G/
41S5K/41S5R/41S5U
RM-862
REF.NO. PART NO. DESCRIPTION REMARK REF.NO. PART NO. DESCRIPTION REMARK
R1650 1-216-033-00 RES,CHIP 220 5% 1/10W
R1651 1-216-073-00 RES,CHIP 10K 5% 1/10W
R1652 1-216-099-00 RES,CHIP 120K 5% 1/10W
R1653 1-216-049-91 RES,CHIP 1K 5% 1/10W
R1654 1-216-049-91 RES,CHIP 1K 5% 1/10W
R1655 1-216-073-00 RES,CHIP 10K 5% 1/10W
R1656 1-216-295-00 SHORT 0
R1701 1-216-065-00 RES,CHIP 4.7K 5% 1/10W
R1702 1-216-065-00 RES,CHIP 4.7K 5% 1/10W
R1703 1-216-065-00 RES,CHIP 4.7K 5% 1/10W
R1704 1-216-065-00 RES,CHIP 4.7K 5% 1/10W
R1705 1-216-065-00 RES,CHIP 4.7K 5% 1/10W
R1706 1-216-065-00 RES,CHIP 4.7K 5% 1/10W
R1707 1-216-025-00 RES,CHIP 100 5% 1/10W
R1708 1-216-025-00 RES,CHIP 100 5% 1/10W
R1709 1-216-025-00 RES,CHIP 100 5% 1/10W
R1710 1-216-049-00 RES,CHIP 1K 5% 1/10W
R1711 1-216-089-00 RES,CHIP 47K 5% 1/10W
R1712 1-216-073-00 RES,CHIP 10K 5% 1/10W
R1713 1-216-089-00 RES,CHIP 47K 5% 1/10W
R1714 1-216-073-00 RES,CHIP 10K 5% 1/10W
R1715 1-216-089-00 RES,CHIP 47K 5% 1/10W
R1716 1-216-033-00 RES,CHIP 220 5% 1/10W
R1717 1-216-089-00 RES,CHIP 47K 5% 1/10W
R1718 1-216-057-00 RES,CHIP 2.2K 5% 1/10W
R1719 1-216-033-00 RES,CHIP 220 5% 1/10W
R1720 1-216-033-00 RES,CHIP 220 5% 1/10W
R1721 1-216-033-00 RES,CHIP 220 5% 1/10W
R1722 1-216-033-00 RES,CHIP 220 5% 1/10W
R1725 1-216-065-00 RES,CHIP 4.7K 5% 1/10W
R1726 1-216-295-00 SHORT 0
R1727 1-216-033-00 RES,CHIP 220 5% 1/10W
R1728 1-216-025-00 RES,CHIP 100 5% 1/10W
R1729 1-216-025-00 RES,CHIP 100 5% 1/10W
R1730 1-216-057-00 RES,CHIP 2.2K 5% 1/10W
R1731 1-216-033-00 RES,CHIP 220 5% 1/10W
R1732 1-216-049-00 RES,CHIP 1K 5% 1/10W
R1733 1-216-049-00 RES,CHIP 1K 5% 1/10W
R1734 1-216-049-00 RES,CHIP 1K 5% 1/10W
R1735 1-216-089-00 RES,CHIP 47K 5% 1/10W
R1736 1-216-033-00 RES,CHIP 220 5% 1/10W
R1737 1-216-033-00 RES,CHIP 220 5% 1/10W
R1738 1-216-025-00 RES,CHIP 100 5% 1/10W
R1739 1-216-073-00 RES,CHIP 10K 5% 1/10W
R1740 1-216-073-00 RES,CHIP 10K 5% 1/10W
R1741 1-216-033-00 RES,CHIP 220 5% 1/10W
R1742 1-216-033-00 RES,CHIP 220 5% 1/10W
R1743 1-216-025-00 RES,CHIP 100 5% 1/10W
R1744 1-216-033-00 RES,CHIP 220 5% 1/10W
R1745 1-216-073-00 RES,CHIP 10K 5% 1/10W
R1746 1-216-025-00 RES,CHIP 100 5% 1/10W
R1747 1-216-025-00 RES,CHIP 100 5% 1/10W
R1748 1-216-025-00 RES,CHIP 100 5% 1/10W
R1749 1-216-033-00 RES,CHIP 220 5% 1/10W
R1750 1-216-073-00 RES,CHIP 10K 5% 1/10W
R1751 1-216-033-00 RES,CHIP 220 5% 1/10W
R1752 1-216-025-00 RES,CHIP 100 5% 1/10W
D
R1521 1-216-097-00 RES,CHIP 100K 5% 1/10W
R1522 1-216-089-91 RES,CHIP 47K 5% 1/10W
R1525 1-216-083-00 RES,CHIP 27K 5% 1/10W
R1526 1-216-083-00 RES,CHIP 27K 5% 1/10W
R1527 1-216-121-91 RES,CHIP 1M 5% 1/10W
R1528 1-216-121-91 RES,CHIP 1M 5% 1/10W
R1529 1-216-025-00 RES,CHIP 100 5% 1/10W
R1530 1-216-097-00 RES,CHIP 100K 5% 1/10W
R1531 1-216-089-00 RES,CHIP 47K 5% 1/10W
R1532 1-216-025-00 RES,CHIP 100 5% 1/10W
R1533 1-249-377-11 CARBON 0.47 5% 1/4W F
R1534 1-216-089-91 RES,CHIP 47K 5% 1/10W
R1537 1-216-073-00 RES,CHIP 10K 5% 1/10W
R1538 1-216-083-00 RES,CHIP 27K 5% 1/10W
R1539 1-216-073-00 RES,CHIP 10K 5% 1/10W
R1540 1-216-091-00 RES,CHIP 56K 5% 1/10W
R1541 1-216-091-00 RES,CHIP 56K 5% 1/10W
R1542 1-216-093-91 RES,CHIP 68K 5% 1/10W
R1543 1-216-093-91 RES,CHIP 68K 5% 1/10W
R1601 1-216-025-00 RES,CHIP 100 5% 1/10W
R1602 1-216-041-00 RES,CHIP 470 5% 1/10W
R1603 1-216-041-00 RES,CHIP 470 5% 1/10W
R1604 1-216-113-00 RES,CHIP 470K 5% 1/10W
R1605 1-216-113-00 RES,CHIP 470K 5% 1/10W
R1606 1-249-397-11 CARBON 22 5% 1/4W F
R1607 1-249-397-11 CARBON 22 5% 1/4W F
R1608 1-249-425-11 CARBON 4.7K 5% 1/4W F
R1609 1-216-081-00 RES,CHIP 22K 5% 1/10W
R1610 1-216-081-00 RES,CHIP 22K 5% 1/10W
R1611 1-249-425-11 CARBON 4.7K 5% 1/4W F
R1614 1-216-357-00 METAL OXIDE 4.7 5% 1W F
R1615 1-216-357-00 METAL OXIDE 4.7 5% 1W F
R1617 1-216-069-00 RES,CHIP 6.8K 5% 1/10W
R1618 1-216-081-00 RES,CHIP 22K 5% 1/10W
R1620 1-216-065-00 RES,CHIP 4.7K 5% 1/10W
R1625 1-216-061-00 RES,CHIP 3.3K 5% 1/10W
R1626 1-216-061-00 RES,CHIP 3.3K 5% 1/10W
R1629 1-216-049-00 RES,CHIP 1K 5% 1/10W
R1630 1-216-081-00 RES,CHIP 22K 5% 1/10W
R1631 1-249-389-11 CARBON 4.7 5% 1/4W F
R1632 1-216-089-91 RES,CHIP 47K 5% 1/10W
R1633 1-216-089-91 RES,CHIP 47K 5% 1/10W
R1634 1-216-081-00 RES,CHIP 22K 5% 1/10W
R1635 1-216-049-91 RES,CHIP 1K 5% 1/10W
R1636 1-216-075-00 RES,CHIP 12K 5% 1/10W
R1637 1-216-049-00 RES,CHIP 1K 5% 1/10W
R1638 1-216-073-00 RES,CHIP 10K 5% 1/10W
R1639 1-216-049-91 RES,CHIP 1K 5% 1/10W
R1640 1-216-025-00 RES,CHIP 100 5% 1/10W
R1641 1-216-065-00 RES,CHIP 4.7K 5% 1/10W
R1642 1-216-049-00 RES,CHIP 1K 5% 1/10W
R1643 1-216-073-00 RES,CHIP 10K 5% 1/10W
R1644 1-216-075-00 RES,CHIP 12K 5% 1/10W
R1645 1-216-041-00 RES,CHIP 470 5% 1/10W
R1648 1-249-381-11 CARBON 1 5% 1/4W F
R1649 1-216-089-00 RES,CHIP 47K 5% 1/10W
